Technical Specification:

Power Requirements:

• NTRL02: +24 VDC (170 mA maximum) from the 24 VDC bus

Inputs:

• Communication link from another TRL termination unit
• Station serial communication link

Outputs:

• Communication link to another termination unit (NTRL02: Minimum power output of the fiber optic transmitter is -15 dBm)
• Station serial communication link
• 24 VDC power to attached stations

Cable Insulation Specifications:

• PVC (UL Rating CL2)
• Non-PVC (UL Rating PLTC)
• 80°C (176°F) at 300 V
• 90°C (194°F) at 300 V

Mounting:

• Occupies one space in a standard INFI 90 field termination panel.

Electromagnetic/Radio Frequency Interference:

• Values are not available at this time. It's recommended to keep the cabinet doors closed and avoid using communication equipment closer than 2 m from the cabinet.

Ambient Conditions:

• Temperature: 0° to 70°C (32° to 158°F)
• Relative Humidity:
  • 0% to 95% up to 55°C (131°F) (non-condensing)
  • 0% to 45% up to 70°C (158°F) (non-condensing)
