Schneider Electric 140CPS12400 Power Supply Module

Ensure uninterrupted power for your critical systems:

• Redundant design for maximum system reliability
• Dual voltage input for global applications
• Complete protection against power issues
• Easy monitoring with status LED indicator
• Certified for hazardous location use

Product Identity

• Brand: Schneider Electric
• Model: 140CPS12400
• Platform: Modicon Quantum Series
• The 140CPS12400 provides backup power safety.
• It uses redundant power supply technology.
• This module prevents system shutdowns.

Electrical Performance

• Input Range: 93-138V AC or 170-276V AC
• Frequency: 47-63 Hz operation
• Output Voltage: 5.1V DC regulated
• Output Current: 8A at 60°C maximum
• Inrush Current: 38A at 115V peak
• Efficiency: >82% typical performance
• Power Factor: >0.95 at full load
• Hold-up Time: 20ms minimum duration

Safety & Protection

• Internal overvoltage protection circuit
• Automatic overload shutdown feature
• 2A slow-blow fuse requirement
• 4kV/8kV ESD protection levels
• FM Class 1 Division 2 certified
• UL 508 and CSA standards compliance
• Low harmonic distortion <10%

Environmental Specifications

• Operating Range: 0°C to +60°C
• Storage Range: -40°C to +85°C
• Humidity Level: 95% non-condensing
• Max Altitude: 5000 meters operation
• EMI Immunity: 10V/m 80-2000MHz
• Vibration Resistance: 2G 10-500Hz

Physical Details

• Module Weight: 1.43 pounds (0.65kg)
• Package Size: 12.4" x 6.5" x 2.0"
• Shipping Weight: 27.4 ounces (778g)
• Green PWR OK LED status indicator
• Standard Quantum module format

Service & Support

• Fast global shipping available
• FedEx, UPS, DHL express options
• Professional packaging protection
• 12-month comprehensive warranty
• Easy return policy available
• Technical support included

Expert Questions Answered

• What does redundant power supply mean?
• It means you can use two units together for backup if one fails.
• Can I use this in hazardous areas?
• Yes, it has FM Class 1 Division 2 certification for safe use.
• How do I select input voltage?
• The unit auto-detects 115V or 230V input without switches.
• What is the power dissipation?
• It calculates as 6W plus 1.5W per output amp used.
• Is this compatible with all Quantum racks?
• Yes, it fits standard Quantum backplanes and connectors.
