Schneider Electric 140XBP00300 Backplane Rack

Solid foundation for your automation system:

• Compact 3-slot design for space-efficient installations
• Universal compatibility with all Quantum I/O modules
• Sturdy metal construction for industrial durability
• Easy screw mounting for secure installation
• Supports local, remote, and distributed I/O configurations

Product Overview

• Brand: Schneider Electric
• Model: 140XBP00300
• Series: Modicon Quantum Platform
• The 140XBP00300 organizes your Quantum modules.
• It serves as a sturdy backplane rack.
• This unit holds three automation modules securely.

Physical Specifications

• Slot Capacity: 3 module slots available
• Backplane Weight: 0.34 kg net weight
• Material: Galvanized steel construction
• Finish: Powder-coated protection
• Thickness: 1.5mm metal gauge
• Color: Standard industrial gray
• Connectors: Gold-plated contacts
• Slot Pitch: 25mm between modules

Mounting & Installation

• Mounting Type: Plate mounting system
• Fixing Method: Screw fastening required
• Screw Size: M4 or #8 recommended
• Mounting Holes: 4 corner holes provided
• Panel Cutout: Not required for mounting
• Orientation: Horizontal or vertical mount
• Clearance: 50mm minimum around unit

Electrical Specifications

• Voltage Rating: 250V AC maximum
• Current Capacity: 10A per slot maximum
• Insulation: 100MΩ minimum resistance
• Dielectric: 1500V AC for 1 minute
• Contact Resistance: <10mΩ per connection
• Backplane Bus: Parallel connection system

Environmental Ratings

• Operating Temp: -25°C to +70°C
• Storage Temp: -40°C to +85°C
• Humidity: 95% non-condensing
• Altitude: 2000 meters maximum
• Corrosion: Salt spray resistant
• Vibration: 5-500 Hz @ 2G
• Shock: 15G for 11ms

Package Information

• Package Type: Single unit (1 PCE)
• Package Weight: 857 grams total
• Package Dimensions: 29.5 x 24.5 x 5.0 cm
• Packaging: Cardboard box with padding
• Units per Carton: 1 individual unit

Compatibility

• All Modicon Quantum local I/O modules
• Quantum remote I/O modules
• Distributed I/O system modules
• Quantum communication modules
• Quantum specialty modules
• Quantum processors and CPUs

Service & Support

• Fast international shipping
• FedEx, UPS, DHL delivery
• Protective packaging materials
• 12-month product warranty
• Installation guidance available
• Quality satisfaction guarantee

Technical Questions

• What types of modules can this backplane hold?
• It holds all Quantum I/O, communication, and processor modules.
• How many modules fit in this backplane?
• Three standard Quantum modules fit in the three slots.
• What tools do I need for installation?
• You need a screwdriver and appropriate mounting screws.
• Can I mount this backplane in any position?
• Yes, it works in both horizontal and vertical positions.
• Is this compatible with all Quantum systems?
• Yes, it works with local, remote, and distributed systems.
