Schneider Electric 140CFK00400 Analog Output Connection Solution

Essential Technical Specifications

• Brand: Schneider Electric
• Model: 140CFK00400
• Product Type: Non-fused analog output terminal block
• Platform Compatibility: Modicon Quantum automation system
• Connection Points: 4 independent contact sets
• Terminals Per Point: 6 allocated terminals for comprehensive wiring
• Electrical Interface: 50-pin SUB-D female connector
• Wiring Method: Captive screw terminals for secure connections
• Mounting System: Standard DIN rail (35mm)
• Operating Temperature: -25°C to +70°C (-13°F to +158°F)
• Vibration Resistance: Up to 5g for industrial environments

Product Overview and Features

• This CableFast terminal block provides reliable analog signal connections.
• It supports both field power and loop power configurations seamlessly.
• The block offers dedicated interfaces for plus, minus, and shield connections.
• It ensures superior signal integrity in noisy industrial environments.

Module Compatibility Information

• The terminal block works with Quantum analog output modules.
• It directly connects to the 140AVO02000 analog output module.
• You can also use it with the 140ACO02000 current output module.
• This ensures flexible integration within your control system architecture.

Installation and Application Guide

• Mount the block quickly on any standard 35mm DIN rail.
• Use the captive screw terminals for fast and secure wire termination.
• The design provides excellent electromagnetic compatibility performance.
• It maintains stable operation in challenging industrial conditions.

Packaging and Delivery Information

• Each 140CFK00400 ships as one individual unit.
• Package dimensions measure 10.43 x 7.09 x 4.13 inches.
• The shipping weight is approximately 12.8 ounces (363 grams).
• We dispatch orders through FedEx, UPS, and DHL courier services.
• All products include comprehensive 12-month warranty coverage.

Professional FAQ Section

• What wiring configurations does this terminal block support?
• It provides complete interfaces for signal, power, and shield connections across four isolated point sets.
• How does this block maintain signal quality in electrically noisy plants?
• The design incorporates separation between signal and power paths with dedicated shielding terminals.
• Which specific Quantum modules connect directly to this interface block?
• It interfaces directly with analog output modules like the 140AVO02000 and 140ACO02000.
• What are the key advantages of using the CableFast system?
• This system significantly reduces installation time while ensuring consistent, error-free wiring.
• Can this block handle both voltage and current output signals?
• Yes, the terminal configuration supports both signal types with proper field power connections.
