Schneider ATV610D15N4 - Compact Power for Smart Motor Control

Drive Performance

• 15kW (20HP) normal duty capacity
• Ultra-wide 0.1-500Hz frequency control
• Dual operation modes: Normal/Heavy Duty
• Only 65dB quiet operation

Key Specifications

• Output Current: 31.7A (normal), 23.5A (heavy)
• Voltage Range: 380-460V ±10%
• Switching Frequency: 2-12kHz adjustable
• Compact Size: 171x360x233mm (7.7kg)

Smart Features

• 16 programmable speed presets
• Built-in Modbus RTU communication
• 3 expansion slots for customization
• Auto motor slip compensation

Industrial Durability

• Operates in -15°C to +45°C
• Vibration-resistant cabinet mount
• Integrated EMC filtering
• IP20 protection rating

Package Contents

• ATV610D15N4 drive unit
• Mounting accessories
• Quick-start manual
• 12-month full warranty

Shipping Options

• FedEx Express (2-3 days)
• UPS Ground/Air
• DHL International
• Real-time package tracking

Expert Answers

• Q: What motor types are compatible?
  A: Works with most 3-phase motors up to 15kW
• Q: How many I/O connections?
  A: 6 digital, 3 analog inputs, 3 relay outputs
• Q: Can I monitor equipment temperature?
  A: Yes, via dedicated sensor inputs
• Q: What maintenance is required?
  A: Just annual cleaning of cooling vents
• Q: Is phone support available?
  A: 24/7 technical support included

Choose the ATV610D15N4 - powerful control in a space-saving design!
