Schneider ATV610U30N4 - Compact 3kW Variable Speed Drive

Efficient Motor Control

• 3kW (4HP) normal duty capacity
• Precision 0.1-500Hz frequency control
• Ultra-quiet 55dB operation
• Dual power modes (normal/heavy duty)

Technical Highlights

• Output Current: 7.2A (normal), 5.6A (heavy)
• Voltage Range: 380-460V ±10%
• Dimensions: 145×297×203mm (3.135kg)
• Switching Frequency: 2-12kHz adjustable
• Power Consumption: 74W max

Smart Features

• 16 programmable preset speeds
• Built-in Modbus RTU (RJ45)
• 3 expansion slots for I/O options
• Auto motor slip compensation

Industrial Design

• IP20 protection rating
• Integrated EMC filtering
• Operates -15°C to +45°C
• Vibration-resistant construction

Package Options

• Single Unit: 4.383kg (19×30.5×41cm)
• Case of 6: 38.198kg (75×80×60cm)
• Includes mounting hardware and manual
• 12-month warranty

Ideal For

• Small pumps and fans
• Conveyor systems
• Packaging machinery
• HVAC equipment

Technical FAQ

• Q: What's the altitude limit?
  A: 1000m without derating (up to 4800m with derating)
• Q: Can I monitor temperature?
  A: Yes, via dedicated analog inputs
• Q: What maintenance is needed?
  A: Annual cleaning of cooling vents
• Q: Is Ethernet available?
  A: Via optional communication card
• Q: What's the warranty?
  A> 12 months manufacturer coverage

Optimize small motor applications with the ATV610U30N4 - compact power with professional features!
