Schneider ATV610D55N4 Altivar 610 Variable Speed Drive

Product Highlights

• Industrial-grade VFD for 45-55kW (60-75HP) motors
• Integrated EMC Filter (IEC 61800-3 C3 compliant)
• Wide frequency range 0.1-500Hz with adjustable switching
• Comprehensive I/O configuration with 3 analog inputs/outputs

Power Specifications

• Motor Power:
  • 55kW/75HP (Normal Duty)
  • 45kW/60HP (Heavy Duty)
• Current Ratings:
  • 380V: 111.5A (ND), 95.9A (HD)
  • 460V: 99.7A (ND), 84.0A (HD)
• Apparent Power: 79.5kVA (ND), 66.9kVA (HD)

Control Features

• Frequency Control: 0.1-500Hz range
• Switching Frequency: 1-8kHz adjustable (2.5kHz nominal)
• Preset Speeds: 16 programmable
• Transient Capability: 132A for 60s

Connectivity & I/O

• Communication: Modbus RTU via RJ45 (4.8-38.4kbit/s)
• Analog Inputs: 3 (0-10V/0-20mA)
• Digital Inputs: 6 (24VDC, 0-30kHz)
• Relay Outputs: 3 (3A@250VAC)
• Option Slots: 1 for expansion cards

Physical & Environmental

• Dimensions: 290×762×323mm (922mm with EMC)
• Weight: 53kg (net), 70.5kg (packaged)
• Operating Temp: -15°C to +45°C (up to 60°C derated)
• Protection: IP20, Pollution Degree 2

Package & Support

• Includes: ATV610D55N4 drive unit
• 12-month warranty
• Global shipping via FedEx, UPS, DHL

FAQ

• Q: What's the altitude operating limit?
  A: 1000m without derating, up to 4800m with derating
• Q: Can I expand the I/O capabilities?
  A: Yes, via optional expansion cards in Slot A
• Q: What's the noise level during operation?
  A: 78dB maximum during forced convection cooling
