Schneider Electric 140CPS21400C Modicon Quantum Power Supply Module

The 140CPS21400C is a high-performance power supply module for Modicon Quantum automation systems. This Schneider Electric module provides reliable 5.1VDC power for Quantum backplanes and connected modules. It features summable output capability for demanding applications requiring multiple power supplies. The module ensures stable operation in challenging industrial environments.

Input Power Specifications

• Input Voltage: 24 VDC nominal (20-30 VDC operating range)
• Input Current: 3800 mA maximum input current
• Inrush Current: 14 A at 20V, 25 A at 24V startup surge
• Power Interruption: 100 ms maximum acceptable interruption
• Fuse Protection: 5 A slow-blow fuse for circuit protection

Output Power Specifications

• Output Voltage: Regulated 5.1 VDC output
• Output Current: 8 A maximum summable output capacity
• Summable Design: Can be paralleled with other units
• Output Protection: Overvoltage and overload protection
• Power Dissipation: 6W + (1.8 × Iout) thermal calculation

Protection & Safety Features

• Overload Protection: Internal protection against excessive loads
• Overvoltage Protection: Output overvoltage protection circuit
• Alarm Output: 1 NC contact for power supply fault (6A/220V)
• ESD Protection: 4 kV contact, 8 kV air discharge resistance
• EMI Immunity: 9.1 V/m (10 V/m) 80-2000 MHz

Environmental Specifications

• Operating Temperature: 32-140°F (0-60°C) wide range
• Storage Temperature: -40-185°F (-40-85°C)
• Humidity Tolerance: 95% non-condensing relative humidity
• Altitude Rating: Up to 16,404 ft (5,000 m) operation
• Protective Coating: Conformal coating for environmental protection

Monitoring & Indicators

• Status LED: Green LED for power OK indication
• Fault Detection: Comprehensive fault detection system
• Alarm Contact: Normally closed contact for remote monitoring
• Diagnostics: Internal diagnostic capabilities
• Visual Status: Clear visual status indication

Physical Specifications

• Module Format: Standard Quantum form factor
• Net Weight: 1.43 lb (0.65 kg) module weight
• Shipping Weight: 29.1 oz (825 g) packaged weight
• Package Dimensions: 12.3" × 6.4" × 1.8" (31.2 × 16.3 × 4.5 cm)
• Mounting: Standard rack mounting installation

Certifications & Standards

• Safety Standards: UL 508, CSA C22.2 No 142
• Hazardous Locations: FM Class 1 Division 2
• International: cUL, CE marking compliant
• Environmental: RoHS compliant manufacturing
• Quality: Schneider Electric quality standards

System Integration

• Backplane Compatibility: Full Quantum backplane compatibility
• Parallel Operation: Designed for parallel operation
• Load Sharing: Current sharing with other power supplies
• Hot Swap: Supports hot swapping in redundant configurations
• Redundancy: Suitable for N+1 redundant systems

Package Contents

• 140CPS21400C power supply module
• Installation and configuration guide
• Technical specification documentation
• Mounting hardware

Shipping & Warranty Information

• Shipping Methods: FedEx, UPS, DHL available
• Delivery: Fast worldwide shipping
• Warranty: 12-month quality guarantee
• Origin: Schneider Electric manufactured

Expert Questions & Answers

• What does "summable" mean for this power supply?

The 140CPS21400C can be paralleled with other units to increase total current capacity. This allows system expansion without replacing the existing power supply.

• How do I calculate heat dissipation for my system?

Use formula: 6W + (1.8 × output current in amps). For example, at 5A output: 6 + (1.8 × 5) = 15W. Ensure adequate panel ventilation for heat removal.

• What circuit breaker size should I use for input power?

Use a 10A circuit breaker to handle the 25A inrush current. The internal 5A slow-blow fuse provides additional protection for the module itself.

• Can this power supply operate in redundant configurations?

Yes, its summable design supports redundant parallel operation. Use diode isolation modules for proper redundant system implementation.

• What happens during a brownout condition?

The wide input range (20-30VDC) allows operation during voltage dips. The module maintains regulated output down to 20V input, providing brownout protection.
