Schneider TSXAEY800 | Analog Input Module
Manufacturer:
Schneider
Product No.:
TSXAEY800
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
FR
Weight:
445g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🔧 Product Model and Type
| Product Model | TSXAEY800 |
| Range of Product | Modicon Premium Automation Platform |
| Product Type | Analog Input Module |
| Input Level | High Level |
⚡ Electrical and Input Specifications
| Analog Input Type | Current: 0...20 mA, 4...20 mA; Voltage: +/- 10 V, 0...10 V, 0...5 V, 1...5 V |
| Analog/Digital Conversion | 12 bits |
| Nominal Read Cycle Time | 27 ms |
| Fast Read Cycle Time | 3 ms + 3 ms x number of channels |
| Measurement Error | 0.15% to 0.41% of full scale (varies by input type) |
🔋 Isolation and Protection
| Isolation Between Channels and Bus | 1000 Vrms |
| Isolation Between Channels and Ground | 1000 Vrms |
| Input Overvoltage Protection | -15…15 V at state 0, -30…30 V at state 1 (250 Ohm) |
| Overcurrent Protection | -30…30 mA at state 1 (250 kOhm) |
📏 Physical and Environmental Specifications
| Operating Temperature | 0…60 °C |
| Storage Temperature | -25…70 °C |
| Relative Humidity | 10…95% for operation, 5…95% for storage |
| Operating Altitude | 0...2000 m |
⚙️ Certifications and Standards
| Certifications | DNV, RINA, GL, BV, LR, RMRS, ABS |
| Standards | IEC 1131 |
| Protection Degree | IP20 |
| Pollution Degree | 2 |
📦 Packing and Shipping Details
| Package Type | PCE |
| Number of Units | 1 |
| Package Dimensions | Height: 5.5 cm, Width: 18.0 cm, Length: 26.0 cm |
| Package Weight | 445.0 g |
🔧 New Parameters
| Current Consumption | 270 mA at 5 V DC |
| Common Mode | None |
| Electrical Connection | 1 SUB-D 25 connector |
| Module Format | Standard |
| Marking | CE |
