SE4302T01 Emerson DC High-Side Module
Manufacturer:
Emerson
Product No.:
SE4302T01
Condition:
In Stock
Product Type:
DC High-Side Module
Product Origin:
USA
Weight:
250g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
Device Type
| Specification | Details |
|---|---|
| Device Type | 24 V DC Solenoid Coils |
| On State Output Rating | Continuous: 100 mA @ 24 V DC |
| Off-State Leakage Current | Maximum: 1 mA |
| Line Fault Detection | Guaranteed Short Circuit: <50 Ω Load Guaranteed Good Status: 240 Ω to 10 kΩ Load Guaranteed Open Circuit: >20 kΩ Load |
| Configurable Output Behavior | Momentary Output Continuous Pulse Output Line Fault Testing |
| Line Fault Test Timing | 200 µsec |
| Field Circuit Protection | Current Limiting Circuit: 200 mA Field Wiring Disconnect: Integrated protection feature |
| CHARM Power Requirements | Standard Terminal Block: 116 mA max @ 24 V DC Relay Output Terminal Block: 24 mA max @ 24 V DC |
| CHARM Heat Dissipation | Pulse Count: 0.1 Hz to 10 KHz Minimum Pulse Width: 50 µsec |
| Operating Temperature Range | -20°C to +60°C |
| Humidity Range | 0% to 95% non-condensing |
| Mechanical Life | 10 million cycles |
| Electrical Life | 1 million cycles at rated load |
| Mounting Type | DIN rail or panel mount |
| Weight | 250 grams (approx.) |
