SE4305T01 Emerson Digital Input Characterization Module
Manufacturer:
Emerson
Product No.:
SE4305T01
Condition:
In Stock
Product Type:
Digital Input Characterization Module
Product Origin:
USA
Weight:
150g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Specification | Details |
|---|---|
| Detection Levels | On State: > 2.1 mA Off State: < 1.2 mA |
| Channel Impedance | 1 kΩ ± 10% |
| Wetting Voltage | 8 VDC ± 1 VDC |
| Isolation | Galvanically isolated according to EN 60079-11 Voltage Peak Value: 375 VDC |
| Power Requirements | CHARM Power Requirement: 28 mA max @ 24 VDC ± 10% |
| Heat Dissipation | 0.57 W |
| Fault Detection Capabilities | Guaranteed Short Circuit: < 200 Ω Guaranteed Good Status: 360 Ω to 19 kΩ Guaranteed Open Circuit: > 40 kΩ |
| Operating Temperature Range | -20°C to +60°C |
| Humidity Range | 0% to 95% non-condensing |
| Response Time | < 10 ms for state change |
| Mounting Options | DIN rail mountable or panel mountable configurations available. |
| Weight | Approximately 150 grams |
