SICK S32B-3011EA Safety Laser Scanner | S300 Mini Remote Series
The S32B-3011EA is a compact safety laser scanner from SICK. It offers reliable area protection for indoor applications. This device helps create safe working environments around machinery.
Key Features & Applications
- Product Family: Part of the SICK S300 Mini Remote safety scanner series.
- Application: Designed for indoor safety monitoring and personnel protection.
- System Compatibility: Works within SICK EFI systems with Flexi Soft controllers.
- Compact Design: Small size allows flexible mounting in tight spaces.
- Reliable Protection: Creates invisible safety zones around hazardous areas.
Technical Specifications
- Model: SICK S32B-3011EA (Alt. Part #: 1056431).
- Protective Field: 3 meters range for immediate danger zone.
- Warning Field: 8 meters range at 15% reflectivity.
- Scanning Angle: Wide 270° coverage area.
- Distance Range: Measures up to 30 meters maximum.
- Field Configuration: 16 field sets, total 48 individual fields.
- Angular Resolution: Precise 0.5° measurement accuracy.
- Response Time: Fast 80 ms reaction for safety signals.
- Resolution Options: Configurable from 30mm to 150mm.
Electrical & Physical Properties
- Power Supply: 24V DC operating voltage (16.8-30V range).
- Outputs: 2 PNP semiconductor outputs, short-circuit protected.
- Connection: 250mm cable with male M12 7-pin connector.
- Enclosure: Aluminum die-cast housing, IP65 rated.
- Dimensions: 102 x 116 x 105 mm (W x H x D).
- Weight: Lightweight at 0.8 kg without cables.
- Color: Yellow (RAL 1021) and black (RAL 9005) housing.
Advanced Functions
- Monitoring Cases: Supports up to 32 different cases.
- Field Switching: Both static and dynamic protective field switching.
- Multiple Sampling: Configurable from 2 to 16 samples.
- Reset Delay: Adjustable from 2 to 60 seconds.
- Contour Reference: Yes, for stable reference measurements.
- EFI Communication: Safe device communication via EFI protocol.
Packaging & Support
- Packaging: Includes scanner unit with 250mm connection cable.
- Shipping: Worldwide delivery via FedEx, UPS, and DHL.
- Warranty: 12-month quality assurance period.
Frequently Asked Questions
- What is the main purpose of this safety scanner?
It creates protective fields around dangerous machinery. When someone enters the zone, it sends stop signals to prevent accidents.
- Can I use it outdoors?
No, the S32B-3011EA is designed for indoor use only. Outdoor models in the S300 series have different specifications.
- How many safety zones can I configure?
You can set up to 48 individual fields organized into 16 field sets. This allows complex safety area designs.
- What's the difference between protective and warning fields?
The protective field (3m) triggers immediate machine stop. The warning field (8m) can activate alerts before entering danger zone.
- Do I need additional controllers?
Yes, it requires a safety controller like SICK Flexi Soft. The scanner connects to form a complete safety system.
