Siemens 6ES7307-1BA01-0AA0 Power Supply: Perfect for S7-300 Systems
- S7-300 Compatible: Designed specifically for SIMATIC S7-300 PLC systems
- Clean Power: Low ripple for sensitive electronic equipment
- Hazardous Area Certified: Safe for use in explosive atmospheres
Product Overview
The Siemens 6ES7307-1BA01-0AA0 PS307 power supply delivers reliable 24V DC power for automation systems. Specifically designed for S7-300 PLCs, it ensures stable operation. Certified for hazardous locations.
Technical Specifications
- Product Code: 6ES7307-1BA01-0AA0
- Output Power: 24V DC / 2A
- AC Input: 85-132V / 170-264V AC
- Efficiency: 84% typical
- Total Power: 48W maximum
- Ripple: 5mV typical, 50mV maximum
- Backup Time: 20ms power hold
- Response Time: 0.5ms for load changes
- Operating Temp: 0°C to +60°C
- Protection Class: IP20
- Short-circuit Current: 9A peak
- Parallel Operation: Up to 2 units
- Mounting: S7 rail only
- Dimensions: 40 x 125 x 120 mm
- Weight: 0.4 kg
- Hazardous Certifications: ATEX, IECEx, UL Hazloc
- Reliability: 2,320,078 hours MTBF
Expert Questions & Answers
What makes this power supply special for S7-300 systems?
It mounts directly on S7 rails and provides clean, stable power specifically designed for PLC and module requirements.
Can it be used in hazardous areas?
Yes, it carries ATEX, IECEx and UL Hazloc certifications for use in potentially explosive atmospheres.
How clean is the output power?
Very clean with only 5mV typical ripple, ensuring reliable operation for sensitive digital electronics.
What happens during a short circuit?
It automatically shuts down and restarts when the fault clears, protecting connected equipment.
Is the voltage adjustable?
No, it provides fixed 24V output optimized for S7-300 system requirements.
