TR CEV65M-50085 Absolute Rotary Encoder – PROFIBUS DP + SSI Dual Interface

• Brand: TR Electronic
• Model: TR CEV65M-50085
• Category: Absolute Rotary Encoder – PROFIBUS DP + SSI
• Manufacturer Part No.: TR-CEV65M-50085
• Author: Ubest Automation

Core Technical Specifications

• Resolution & Measurement Range
  Steps per revolution: 4,096,000. Number of revolutions: 4,096,000. Total resolution equals 24 bits.
• Dual Interface & Output Levels
  Interface: PROFIBUS DP plus SSI. Output levels support RS422 and RS485. PROFIBUS baud rate up to 12 Mbaud.
• Programmable Code & Profile
  Code type is programmable. Options include PNO-Profile Class 2 for enhanced compatibility.
• Supply & Electrical Data
  Supply voltage range 11-27V DC. Encoder conforms to PROFIBUS DP Class 2 specifications.
• Temperature & Environmental Tolerance
  Working temperature range -20 to +70°C (also rated 0-60°C). Protection class IP65 resists dust and water jets.
• Mechanical Design
  Flange type ZB36. Shaft type 10FL/19,5. Connector position: PG radial.
• Connector & Pinout
  Connectors: 2x M16x1.5 and 1x M12x1.5. Pinout No. TR-ECE-TI-GB-0018. Mating plugs not included.
• Firmware & Documentation
  Firmware No. 437826. Drawing No. 04-CEV65M-M0133. Documentation No. DOKUMENTE.

LED Status Indicators – Link & Data Activity

• ON (Green) – Ethernet link established. The device has a physical network connection.
• Flashing (Green) – Data activity. The encoder is transmitting or receiving data (TxD/RxD).

LED Status Indicators – Network Status

• OFF – No power or no IP address. The device lacks supply voltage or IP assignment.
• 1 Hz (Green) – No connections but IP address assigned. The device waits for active connections.
• ON (Green) – Connection established. The device has at least one active connection (e.g., Message Router).
• 1 Hz (Green/Red) – Self-test. The device performs power-up testing.

Frequently Asked Questions

• Q: Can I use both PROFIBUS DP and SSI interfaces at the same time?
  A: Yes. The TR CEV65M-50085 supports dual interface operation for redundant feedback paths.
• Q: What does a flashing green LED mean on Link/Data Activity?
  A: A flashing green LED indicates active data transfer (TxD/RxD) on the network.
• Q: How do I fix a duplicate IP address error?
  A: Change the encoder's IP address to a unique value. The device will show a solid red LED until you resolve the conflict.
• Q: What is the maximum PROFIBUS baud rate?
  A: The encoder supports up to 12 Mbaud with the ENC 12MBAUD option.
• Q: Does this encoder support PNO-Profile Class 2?
  A: Yes. The ENC PNO-PROFILE CLASS.2 option ensures full compatibility with PROFIBUS DP Class 2 networks.
