TREXCHPKLWS1 Emerson AMS Trex Intrinsically Safe Communicator

Core Technical Highlights

• Processor & Memory: An 800 MHz ARM Cortex A8/NXP microprocessor handles complex tasks. It includes 512 MB DDR3 SDRAM for smooth multitasking. Internal flash provides 2GB NAND plus 32GB extended storage.
• Operating System: The device runs on Windows Embedded Compact 2013. This ensures a responsive and familiar user interface.
• Display: Technicians view data on a crisp 640 x 480 pixel screen. The touch interface works reliably even with gloves.
• Power & Communication: A rechargeable Li-Ion Power Module (Type P) supports full-day fieldwork. The integrated HART Application (H) enables deep device diagnostics.
• Wireless & Certification: This TREXCHPKLWS1 includes Wireless option (W). It holds KL certifications: ATEX, CSA (US/Canada), and IECEx Intrinsically Safe.

Environmental & Hazardous Area Resilience

• Intrinsically Safe Design: Engineers can safely connect to live circuits in explosive atmospheres. Certifications include FISCO for fieldbus applications.
• Temperature Range: The unit operates reliably from -20°C to +60°C. It withstands extreme cold and heat in outdoor plants.
• Durability: The rugged housing resists shocks and drops on industrial sites. It also rejects electromagnetic interference for stable HART loops.
• Resolution & Linearity: High-resolution signal detection ensures accurate device adjustments. It maintains excellent linearity for valve calibration.

Complete Technical Specifications

• Brand: Emerson
• Model Number: TREXCHPKLWS1
• Series: AMS Trex Device Communicator
• Communication Module: C = Device Communicator module with HART Application (H)
• Power & Radio: Type P Rechargeable Li-Ion with Wireless (W) option
• Certifications: KL = ATEX, CSA, IECEx Intrinsically Safe (includes FISCO)
• Support: S1 = Standard Support (1 Year)
• Frequency Response: Optimized for HART protocol communication
• Author: Ubest Automation

Installation & Quick Start Guide

• Connect the TREXCHPKLWS1 leads to the HART device terminals. Polarity does not matter for basic communication.
• Power on the unit; the operating system loads in under 30 seconds. The device automatically polls for connected instruments.
• Navigate the HART application menu using the touch screen. Select your specific device model from the recognized list.
• Follow on-screen instructions for configuration or diagnostics. Use the wireless module for secure data transfer to AMS software.

Frequently Asked Questions (FAQ)

• Can I use this communicator in Zone 0 hazardous areas? Yes, the KL certification includes ATEX and IECEx Intrinsically Safe ratings. It is suitable for Zone 0, 1, and 2 installations.
• How do I update the device firmware? Use the built-in wireless connection (W) to download updates. You can also load updates via the USB port from a PC.
• What is the advantage of the 32GB extended flash? It allows you to store hundreds of device configurations and screen captures. This proves invaluable for large plant turnarounds.
• Does this model include the battery? Yes, the package includes the Rechargeable Li-Ion Power Module (Type P).
