Triconex 3805H Analog Output Module

The Triconex 3805H is a high-precision analog output module. This module provides eight 4-20mA output channels. Triconex designed it with TMR technology for maximum reliability.

Technical Specifications

• Brand: Triconex
• Model:3805H
• Module Type: TMR Analog Output
• Output Channels: 8 points
• Output Range: 4-20 mA (+6% overrange)
• Resolution: 12 bits
• Accuracy: ±0.25% of full scale
• Loop Power: 24 VDC nominal (42.5 VDC max)
• Load Capacity: Up to 1000 ohms
• Response Time: < 10 ms on leg failure
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Output Type: DC coupled, common return

Package Contents

• One 3805H analog output module
• Installation documentation
• Mounting hardware
• Connection guide

Shipping & Support

• Worldwide shipping via FedEx, UPS, DHL
• 12-month warranty
• Fast order processing available
