Triconex 4000093-310 Input Terminal Cable Assembly

The Triconex 4000093-310 input terminal cable delivers reliable performance for safety and control systems.

Key Specifications

• Manufacturer: Triconex; Model:4000093-310; product type: input terminal cable assembly.
• Wire Gauge: 18 AWG with low resistance and stable current handling in tight installations.
• Max Current Capacity:4 A per conductor, suitable for typical input terminal loads.
• Operating Temperature:-45°C to +80°C for harsh plant environments and cold climates.
• Impedance: 100 Ohms to support consistent signal matching in long runs and terminated networks.

Electrical & Mechanical Details

• Voltage Rating:1000 V, providing strong insulation margin for industrial signals and control lines.
• Capacitance: 40 pF/m typical, enabling low coupling and maintained signal fidelity over distance.
• Resistance: 1.0 Ohms/km, ensuring low conductor loss in medium-length installations for reliable measurements.
• Insertion Loss: 1.5 dB per 100 m, keeping signal attenuation minimal for process communication links.
• Dielectric Strength: 2000 V, tested to withstand transient voltages and protect connected devices.

Installation Guide

• Route the cable away from heavy power lines to reduce electromagnetic interference and maintain signal quality.
• Use proper strain relief at both ends to reduce mechanical stress on connectors and conductors over time.
• Maintain minimum bend radius of ten times the cable diameter to prevent conductor fatigue or damage.
• Terminate with correct shielding and grounding to ensure an effective return path and low noise floor.

Packaging & Shipping

• Package includes one complete Triconex input terminal cable assembly with secure protective wrapping and labels.
• We ship via FedEx, UPS, or DHL according to customer preference and delivery urgency.
• Warranty:12 months from shipment date against manufacturing defects under normal use.

Product Highlights

• Low capacitance and low insertion loss for accurate signal transmission over control distances.
• Wide temperature range supports outdoor cabinets and cold-room installations without performance loss.
• High voltage rating and strong dielectric strength for added safety in harsh industrial systems.
• 18 AWG conductors balance flexibility with current capacity for typical terminal loads and wiring runs.
• Lightweight and flexible design simplifies routing inside tight control panels and trays.

Technical Additions

• Shield coverage: braided copper plus foil for ≥95% shielding effectiveness against EMI sources.
• Jacket material: PVC standard with UV and oil resistance for long field life in plants.
• Connector options: available with keyed locking ends for secure mating in harsh vibration zones.
• Color options: standard gray jacket; custom colors available for panel identification on request.
• Test report: optional factory electrical test and continuity report available upon order request.

FAQ

• Q: Can this cable run inside the same tray with power cables?
• A: Avoid running the cable with high voltage power lines to reduce EMI and preserve signal integrity.
• Q: Do you offer custom lengths or termination types?
• A: Yes, we provide custom lengths and connector types to match specific panel and system needs.
• Q: How do I clean or maintain the cable in the field?
• A: Wipe the jacket with a damp cloth and mild detergent; avoid aggressive solvents that damage insulation.
• Q: What is the recommended maximum continuous current per conductor?
• A: The cable handles 4 A continuous; do not exceed this rating to avoid heating and degradation.
• Q: How do you ensure quality before shipment?
• A: We perform visual, continuity, and dielectric tests to ensure each assembly meets our standards.
