Triconex 4000103-520 Cable Assembly Specifications

The Triconex 4000103-520 Cable Assembly delivers high power transmission with superior durability. It supports fast and reliable connections in industrial environments, designed for consistent performance and long service life.

Technical Highlights

• Weight: 0.29 kg for easy handling and installation
• Wire Gauge: 14 AWG ensures low voltage drop and efficient current flow
• Max Current Capacity: 6 A for high-demand power systems
• Voltage Rating: 1500 V for safe and stable operation
• Operating Temperature: -40°C to +90°C for all-weather reliability
• Capacitance: 50 pF/m minimizes signal loss
• Resistance: 0.4 Ohms/km for energy-efficient performance
• Dielectric Strength: 3000 V for superior insulation
• Flexibility: Tested over 750,000 flex cycles for extended cable life

Additional Technical Parameters

• Shield Type: Braided copper for EMI protection
• Insulation Material: Cross-linked polyethylene (XLPE)
• Outer Jacket: PVC rated for oil and chemical resistance
• Bend Radius: 8 × cable diameter minimum
• Signal Integrity: Low attenuation for data reliability

Key Selling Points

• Built for demanding automation and process control systems
• Maintains stable signal and power delivery under heavy load
• Engineered to reduce interference in noisy environments
• Compact and lightweight for simplified routing
• Designed by Triconex for long-lasting reliability

Installation Guide

• Ensure connectors are aligned before locking
• Avoid sharp bends below the minimum bend radius
• Keep away from high-heat or corrosive surfaces
• Inspect connectors before powering the system

Packing List

• 1 × Triconex 4000103-520 Cable Assembly
• Protective industrial packaging
• Product identification label

Shipping & Warranty

• Shipping via FedEx, UPS, or DHL worldwide
• 12-month full warranty against manufacturing defects

Frequently Asked Questions (FAQ)

• Q1: What is the main use of the Triconex 4000103-520 Cable Assembly?
  A1: It connects I/O modules and control systems in industrial automation.
• Q2: Can it handle outdoor installation?
  A2: Yes, the wide temperature range and PVC jacket protect against harsh conditions.
• Q3: Is the cable flexible enough for moving machinery?
  A3: Yes, it supports over 750,000 flex cycles for repetitive motion systems.
• Q4: What kind of connector fits this cable?
  A4: It is compatible with standard Triconex I/O and field termination connectors.
• Q5: How can I order or get a quotation?
  A5: Contact us at sales@ubestplc.com or +86 18030005825 on WhatsApp.
