KJ1501X1-BC3 Emerson | System Dual DC Power Supply
VE3008 KJ2005X1-MQ1 12P6381X042 DeltaV MQ Controller
KJ1501X1-BC3 Emerson | System Dual DC Power Supply
VE3008 KJ2005X1-MQ1 12P6381X042 DeltaV MQ Controller
Emerson

VE5009 KJ1501X1-BC3 | DeltaV System Power Supply

In stock
Manufacturer:
Emerson
Product No.:
VE5009
Condition:
In Stock
Product Type:
System Power Supply
Product Origin:
USA
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

VE5009 DeltaV System Power Supply

Parameter Details
Model VE5009 KJ1501X1-BC3
Manufacturer DeltaV

DeltaV Power Specifications

Parameter Details
Input Voltage 12 VDC (-4-5%) at 14.8 A, 24 VDC ±20% at 6.1 A
Inrush (Soft Start) 12 A peak maximum for 5 ms over 12 VDC input range (excluding 12 VDC output), 20 A peak maximum for 5 ms over 24 VDC input range (including 12 VDC output)
Output Power Rating (-40 to 60°C)
  • +12 VDC at 13 A (12 VDC Input)
  • +12 VDC at 8.0 A (24 VDC Input)
  • +5 VDC at 2.0 A
  • +3.3 VDC at 2.0 A
  • 10 W total for combined outputs of +5 VDC and +3.3 VDC
Output Power Rating (60 to 70°C)
  • +12 VDC at 10 A (12 VDC Input)
  • +12 VDC at 6.0 A (24 VDC Input)
  • +5 VDC at 2.0 A
  • +3.3 VDC at 2.0 A
  • 10 W total for combined outputs of +5 VDC and +3.3 VDC

DeltaV Protection and Performance Specifications

Parameter Details
Input Protection Internally fused, non-replaceable
Overvoltage Protection Output protected at 110% to 120%
Hold-up Time Output remains within 5% of nominal at full load and minimum input voltage for 5 ms (excluding 12 VDC current with 12 VDC input)
