Bently Nevada 9200-06-02-02-00 Seismoprobe - Industrial Vibration Monitoring Made Simple

Precision Vibration Sensing

The Bently Nevada 9200-06-02-02-00 two-wire velocity transducer delivers reliable vibration data for rotating machinery. Perfect for predictive maintenance in harsh industrial environments.

Key Benefits

• 10Hz minimum frequency for early fault detection
• Wide temp range (-29°C to +121°C operating)
• 0.100" peak-peak dynamic range
• Lightweight 300g design
• Side-mount connector for easy installation

Technical Details

• Part Number: 9200-06-02-02-00
• Type: Two-Wire Velocity Transducer
• Frequency Range: 10Hz to 1000Hz
• Sensitivity: 200mV/in/s ±5%
• Coil Resistance: 1.25kΩ ±5%
• Mounting: 1/4-28 UNF stud
• Ingress Protection: IP65 rated
• Shock Survival: 100g peak

Why Choose This Model?

• Proven reliability in oil/gas applications
• No external power needed (two-wire operation)
• Circular base fits standard mounts
• Bently Nevada quality since 1961

Warranty & Shipping

• 12-month warranty
• Fast global delivery via FedEx, UPS, DHL
• Tracking provided for all orders

Installation Tips

• Mount on clean, flat surfaces only
• Use lockwasher with mounting stud
• Keep cable runs under 300m
• Avoid electrical noise sources

Technical FAQs

• Q: What's the lifespan?
  A: 5+ years typical in industrial service
• Q: Can it monitor axial vibration?
  A: No - radial vibration only
• Q: Is calibration required?
  A: Factory calibrated - field verification optional
• Q: What cable type recommended?
  A: Shielded twisted pair, 22AWG minimum
• Q: Compatible with 9200 series monitors?
  A: Yes - designed for seamless integration
