Bently Nevada 9200 Seismoprobe: Advanced Vibration Monitoring

The 9200-09-01-02-00 from Bently Nevada delivers precision vibration measurement for industrial applications. This two-wire velocity transducer provides reliable performance in demanding environments. The seismoprobe design ensures accurate data collection for predictive maintenance programs.

Product Configuration Architecture

• Core Model: 9200 - Two-Wire Velocity Seismoprobe Transducer
• Mounting & Frequency: 09 - 0±180°, 15 Hz Minimum Operating Frequency
• Connection System: 01 - Top Mount Connector Configuration
• Mounting Base: 02 - Circular Base with 1/4-28 UNF Stud
• Certification Status: 00 - Standard Industrial Compliance

Enhanced Technical Specifications

• Frequency Range: 15 Hz to 2,000 Hz (900 to 120,000 CPM)
• Sensitivity Rating: 100 mV/in/sec ±5% at 25°C
• Velocity Range: 0-25.4 mm/s (0-1.0 in/s) peak
• Coil Resistance: 1.25 kΩ ±5% at 25°C
• Operating Temperature: -29°C to +121°C (-20°F to +250°F)
• Storage Temperature: -40°C to +125°C (-40°F to +257°F)
• Dynamic Range: 2.54 mm (0.100 inch) peak-to-peak
• Weight Specification: 300 grams (10.5 ounces)
• Shock Resistance: 100 g peak mechanical shock
• Vibration Limit: 50 g peak operating vibration

Key Product Advantages

• Two-wire system simplifies installation and reduces wiring costs
• Top mount connector allows easy access in confined spaces
• Circular mounting base with UNF stud ensures secure attachment
• Wide temperature range supports extreme environment operation
• Low frequency response detects early mechanical problems
• Robust construction withstands harsh industrial conditions
• Velocity output directly compatible with monitoring systems
• Minimal phase shift across entire frequency range

Installation & Application Guidelines

• Mount transducer vertically for optimal performance
• Ensure clean, flat surface for base mounting contact
• Use proper torque for 1/4-28 UNF stud installation
• Maintain cable bend radius greater than 25 mm
• Verify electrical isolation from ground potential
• Check connector sealing for outdoor applications

Package Contents

• 9200 Series Seismoprobe Transducer unit
• Mounting hardware and installation guide
• Technical specifications sheet
• Calibration certificate documentation

Warranty & Shipping Details

• 12-month comprehensive manufacturer warranty
• Global express shipping via FedEx, UPS, DHL
• Standard delivery within 2-4 business days
• Tracking information provided for all shipments

Professional Frequently Asked Questions

• What applications suit this velocity transducer best?
  Ideal for pump, motor, fan, and compressor vibration monitoring. The 15 Hz low frequency response detects imbalance and misalignment in rotating equipment effectively.
• How does the two-wire design benefit installation?
  The two-wire system reduces wiring complexity and installation time. It provides both power and signal transmission through the same cable pair.
• What mounting orientation provides optimal results?
  Vertical mounting delivers the most accurate measurements. The transducer can operate in any orientation but may require calibration adjustments.
• Can this transducer withstand high shock environments?
  Yes, the robust construction handles up to 100 g mechanical shock. The internal damping system protects sensitive components from impact damage.
• What maintenance does the transducer require?
  Routine visual inspection and connector cleaning ensure long-term reliability. The sealed design typically requires no internal maintenance.
