GE Fanuc VersaMax IC200ALG260: Precision 8-Channel Analog Input Module

Core Functionality

12-bit resolution analog input module for industrial automation. Handles voltage (±10V) and current (4-20mA) signals across 8 isolated channels. Ideal for precise process monitoring.

Key Technical Specifications

• Brand: GE Fanuc
• Model: IC200ALG260 (Version C)
• Series: VersaMax
• Input Channels: 8 isolated
• Resolution: 12-bit (4096 steps)
• Measurement Range: ±10VDC or 0-10V configurable, 4-20mA
• Isolation: 250VAC continuous / 1500VAC for 1 minute
• Input Impedance: 126kΩ max (voltage)
• Backplane Power: 130mA max @5VDC
• Dimensions: 4.5" x 2.5" x 2.5" (114mm x 63mm x 63mm)
• Weight: 0.3 kg

Environmental Robustness

• Operating Temp: -20°C to 70°C (industrial range)
• EMI Protection: High noise immunity design
• Vibration Resistance: 5g @ 10-500Hz

Installation & Compatibility

• DIN rail mounting (tool-less)
• Hot-swappable with VersaMax systems
• Vertical/horizontal orientation support

Diagnostics & Maintenance

• Channel-level fault indicators
• Automatic calibration
• No periodic servicing required

Certifications & Support

• UL/cUL/CE certified
• Warranty: 12 months
• Shipping: FedEx/UPS/DHL (global)

FAQs

• Q: Can I mix voltage/current inputs?
  A: Yes, per-channel configuration available.
• Q: Sampling rate per channel?
  A: 10ms update rate for all channels.
• Q: Requires external signal conditioning?
  A: No, direct sensor connection.
