Toshiba VFS15-4075PL-W1 AC Variable Frequency Drive

The VFS15-4075PL-W1 delivers high-performance motor control for industrial applications. This Toshiba micro-drive provides precise speed regulation for three-phase motors. The compact S15 Series drive offers flexible control and reliable operation in various conditions.

Core Specifications

• Brand: Toshiba Motors & Drives
• Model: VFS15-4075PL-W1
• Series: Toshiba VF-S15 Series
• Motor Power: 10 HP (7.5 kW)
• Full Load Current: 17 Amps continuous
• Input Voltage: 460 VAC, three-phase
• Output Frequency: 0.1 Hz to 500.0 Hz adjustable
• Default Frequency: 0.5 Hz to 60 Hz standard
• Control Method: Sinusoidal PWM (Pulse Width Modulation)
• Overload Capacity: 110% continuous, 150% for 60 seconds

Performance Features

• Built-in high-attenuation EMC filter for noise reduction
• Safe Torque Off (STO) compliant safety functionality
• Auto-restart operation catches spinning motors smoothly
• Precision control works with permanent magnet (PM) motors
• Compact IP20 enclosure suitable for wall-mount installation
• Extended PID control for accurate level management
• Ten-year design life ensures long-term reliability

Input & Output Configuration

• Six programmable discrete inputs for control signals
• Three programmable discrete outputs for status indication
• Three programmable analog inputs (4-20mA/0-10V/±10V)
• One programmable analog output (4-20mA or 0-10VDC)
• Two-wire RS485 communication port for network connectivity
• Four-digit LED display for operation monitoring
• Rotary encoder feedback support for closed-loop control

Environmental Ratings

• Operating Temperature: -10°C to +50°C (14°F to 122°F)
• Storage Temperature: -20°C to +65°C (-4°F to 149°F)
• Maximum Humidity: 95% relative humidity non-condensing
• Operating Altitude: Up to 1000 meters without derating
• Vibration Resistance: 5.9 m/s² maximum (2-150 Hz range)
• Shock Resistance: 147 m/s² for 11 milliseconds duration

Package Contents

• One Toshiba VF-S15 Series AC drive unit
• Installation and operation manual
• Mounting brackets and necessary hardware
• Terminal connection guide and diagrams
• Express shipping via FedEx, UPS, or DHL available

Frequently Asked Questions

• What motor types can this VFD control effectively? The drive controls standard AC induction motors and permanent magnet motors with excellent precision.
• How does the Safe Torque Off feature enhance safety? This function prevents unexpected motor starts by cutting torque immediately during maintenance.
• Can this unit handle voltage fluctuations in the plant? Yes, it maintains stable operation with typical industrial voltage variations and transient conditions.
• What is the recommended maintenance schedule? We suggest visual inspections every six months and checking connections annually for optimal performance.
• Does the drive support custom acceleration profiles? Yes, you can program multiple acceleration and deceleration ramps for different application needs.

This product includes comprehensive 12-month warranty protection against defects.
