Description

The Yokogawa AAI135-S00 is an 8-channel analog input module that converts analog signals from eight different sensors or transmitters into digital signals for use by a programmable logic controller (PLC) or other control system. It is a standard type module with no explosion protection and no HART communication capabilities.

Technical Specifications

• Input Type: Analog current (4-20 mA)

• Number of Channels: 8

• Input Impedance: 100 Ω

• Accuracy: ±0.2% of full scale

• Resolution: 12 bits

• Output: Digital (binary or BCD)

• Data Bus: FIO bus

• Power Supply: 24 VDC

• Power Consumption: 1.5 W

• Operating Temperature: -10 to 60 °C

• Storage Temperature: -40 to 80 °C

• Dimensions: 107.5 x 94 x 32.8 mm (4.23 x 3.70 x 1.29 in)

• Weight: 320 g (0.71 lb)

Suffix Codes

• -S: Standard type
• 0: Basic type
• 0: No explosion protection
