The Yokogawa AAI143-S00 is a 16-channel isolated analog input module designed for use with Yokogawa CENTUM VP and CENTUM CS series controllers. It supports analog input signals ranging from 4 to 20 mA, offering high precision and reliability.

Key Features:

• 16-channel isolated analog inputs.
• Supports 4 to 20 mA analog input signals.
• High precision: ±0.1% full scale.
• High reliability: MTBF of 100,000 hours.
• Low power consumption.
• Easy installation and maintenance.

Applications:

• Process control.
• Monitoring and alarming.
• Data acquisition.

Technical Specifications:

• Channels: 16
• Input Type: Analog current
• Input Range: 4 to 20 mA
• Accuracy: ±0.1% full scale
• Resolution: 16-bit
• Update Rate: 250 milliseconds
• Isolation: Yes
• Power Consumption: 10 W
• Dimensions: 107.5 x 94 x 32.8 mm
• Weight: 300 g
• Operating Temperature: -20 to +60 °C
• Humidity: 5 to 95% non-condensing

Suffix Codes:

• -S: Standard type
• 0: Always 0
• 0: Basic type

For example, "AAI143-S00" denotes a standard type, basic model of the AAI143 analog input module.
