Yokogawa AAI543-H00 Analog Output Module
Manufacturer:
Yokogawa
Product No.:
AAI543-H00
Condition:
In Stock
Product Type:
Analog Output Module
Product Origin:
JP
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Description:
The Yokogawa AAI543-H00 is a versatile 16-channel isolated current output module designed for industrial automation applications. It provides a 4 to 20 mA output signal and supports HART communication for configuration and diagnostics. The module is suitable for use in redundant configurations to enhance reliability.
Technical Specifications:
- Number of Output Channels: 16
- Output Signal: 4 to 20 mA
- Withstanding Voltage: 1500 V AC between output and system, for 1 minute
- Allowable Load Resistance: 0 to 750 Ω
- Circuit-Open Detection: Less than 0.65 mA
- Accuracy: ±48 μA
- Data Update Period: 10 ms
- Drift due to Ambient Temperature Change: ±16 μA/10°C
- Maximum Current Consumption: 230 mA (5 V DC), 540 mA (24 V DC)
- Weight: Approx. 0.4 kg
- External Communication: Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)
- HART Communication: Available
Suffix Codes:
- -H: With digital communication (HART protocol)
- -0: Standard type module
- -0: Basic type
