Yokogawa AAI543-H00 S1 Analog Output Module
Manufacturer:
Yokogawa
Product No.:
AAI543-H00 S1
Condition:
In Stock
Product Type:
Analog Output Module
Product Origin:
JP
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Description:
The Yokogawa AAI543-H00 S1 is a 16-channel isolated current output module designed for industrial automation systems. It provides a precise 4 to 20 mA output signal and supports HART communication for configuration and diagnostics. This module is suitable for use in redundant configurations to enhance system reliability. It includes the ISA Standard G3 option for expanded functionality.
Technical Specifications:
- Number of Output Channels: 16
- Output Signal: 4 to 20 mA
- Withstanding Voltage: 1500 V AC between output and system, for 1 minute
- Allowable Load Resistance: 0 to 750 Ω
- Circuit-Open Detection: Less than 0.65 mA
- Accuracy: ±48 μA
- Data Update Period: 10 ms
- Drift due to Ambient Temperature Change: ±16 μA/10°C
- Maximum Current Consumption: 230 mA (5 V DC), 540 mA (24 V DC)
- Weight: Approx. 0.4 kg
- External Communication: Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)
- HART Communication: Available
Suffix Codes:
- -H: With digital communication (HART protocol)
- -0: Standard switch-over response in redundant configuration with no explosion protection
- -0: Basic type
- -S1: With ISA Standard G3 option
