The Yokogawa AAI841-S00 is a variant of the AAI841 family, designed for industrial automation systems. This module manages both analog inputs and outputs, making it suitable for a variety of applications where HART communication is not needed.

Functionality

• Analog Input/Output: 8 channels each for input and output
• Signal Range: 4 to 20 mA for both input and output
• Design: Non-isolated (input and output circuits share a common ground)

Technical Specifications

• Accuracy: ±0.1% of full scale
• Resolution: 12 bits
• Update Rate: Typically ranges from 10 to 250 ms
• Power Supply: 24 VDC
• Operating Temperature: -40 to 70°C
• Operating Humidity: 5 to 95% RH (non-condensing)
• Dimensions: 107.5 x 94 x 32.8 mm (4.23 x 3.70 x 1.29 in)
• Weight: 300 g (10.6 oz)

Suffix Code

• -S: Standard type with no additional features like HART communication
• 0  Basic type
