The Yokogawa AAP135-S00/K4A00 is an 8-channel pulse input module designed to convert pulse signals into analog signals. It is versatile and suitable for various industrial applications such as flow measurement, speed measurement, and counting.

Key Features:

• High Accuracy: The module offers a measurement accuracy of ±0.1%, meeting demanding application requirements.
• Wide Range: Operating range from 0.01 Hz to 10 kHz, covering a broad spectrum of pulse frequencies.
• Multiple Input Types: Supports single pulse, double pulse, and quadruple pulse inputs for flexible integration.
• Programmability: Output signals can be programmed via software to meet specific application needs.
• Isolation: Provides isolation between input and output to prevent interference.

Technical Specifications:

• Range: 0.01 Hz to 10 kHz
• Accuracy: ±0.1%
• Input Types: Single pulse, double pulse, quadruple pulse
• Output Signal: 4-20 mA DC
• Power Supply: 24 V DC
• Power Consumption: 2 W
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +80°C
• Protection Rating: IP67

Suffix Code Meaning:

The suffix code "S00/K4A00" for the Yokogawa AAP135-S00/K4A00 module indicates:

• S00: Standard type with no explosion protection
• K4A00: Includes a KS Cable Interface Adapter (Model: ATK4A-00)

This suffix code provides information about the module's standard configuration and additional options, specifically the inclusion of a KS Cable Interface Adapter, which facilitates connectivity in specific installation scenarios.
