The Yokogawa AAP135-S00 S2 is a pulse input module designed to convert pulse signals into analog signals. It is suitable for various industrial applications such as flow measurement, speed measurement, and counting.

Key Features:

• High Accuracy: The module offers measurement accuracy of ±0.1%, meeting stringent application requirements.
• Wide Range: Operating range from 0.01 Hz to 10 kHz, covering a wide range of pulse frequencies.
• Multiple Input Types: Supports single pulse, double pulse, and quadruple pulse inputs.
• Programmability: Output signals can be programmed via software to meet specific application needs.

Technical Specifications:

• Range: 0.01 Hz to 10 kHz
• Accuracy: ±0.1%
• Input Types: Single pulse, double pulse, quadruple pulse
• Output Signal: 4-20 mA DC
• Power Supply: 24 V DC
• Power Consumption: 2 W
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +80°C
• Protection Rating: IP67

Suffix Code Meaning:

The suffix code "S00 S2" for the Yokogawa AAP135-S00 S2 module indicates:

• S00: Standard type with no explosion protection (S for Standard, 00 for no explosion protection)
• S2: Second version of the module

This suffix provides information about the module's standard configuration and version, ensuring clarity in deployment and compatibility within industrial environments.
