Schneider Electric Quantum 140CPU67261 Unity Processor

The 140CPU67261 is a high-performance Unity Processor for the Modicon Quantum series from Schneider Electric. This powerful CPU module runs at a fast 266 MHz clock speed for demanding automation tasks. It ensures maximum system uptime with its integrated hot standby processor feature. You can connect it easily to various networks using its multiple communication ports.

Key Technical Specifications

• Brand & Model: Schneider Electric 140CPU67261 Unity Processor.
• Processor Speed: High-performance 266 MHz CPU for fast execution.
• Memory: Equipped with 3072 KB of RAM for program and data.
• Communication: Built-in Ethernet, Modbus, and Modbus Plus ports.
• Operating Temp: Reliable operation from 0°C to 60°C.
• Storage Temp: Can be stored from -40°C to 85°C.
• Bus Current: Requires 2760 mA from the Quantum base rack.
• Local Racks: Can control and manage up to 2 local racks.

Advanced System Features

• Integrated hot standby processor support for system redundancy.
• Accurate time stamping capability for precise I/O event logging.
• Handles high-speed interrupt inputs for immediate process response.
• Full support for counter I/O and serial link I/O modules.
• Compatible with single-mode transmission for network communication.
• Rack-mountable design for easy installation in control cabinets.

Installation Guide

• Install the module in the CPU slot of a Modicon Quantum 140 XBP rack.
• Ensure the base rack power supply meets the 2760 mA current requirement.
• Use the appropriate communication cables for Ethernet or Modbus networks.
• Always follow the official Schneider Electric installation manual procedures.

Packaging & Shipping Information

• Product ships in original factory packaging for full protection.
• Package includes the 140CPU67261 CPU module and documentation.
• We ship worldwide using FedEx, UPS, and DHL express services.
• Orders typically process and ship within 1-2 business days.

Frequently Asked Questions

• What is the processor speed?
• The CPU operates at 266 MHz.
• What networks does it support?
•  It has Ethernet, Modbus, and Modbus Plus.
• Is this a redundant CPU?
• Yes, it supports hot standby configuration.
• How much memory is available?
• The module has 3072 KB of RAM.
• What is the operating temperature?
•  It works from 0°C to 60°C.
