Siemens 6GK1901-1BB10-2AA0 Industrial Ethernet RJ45 Plug

This is a strong and reliable RJ45 plug for factory networks. The 6GK1901-1BB10-2AA0 makes connecting Industrial Ethernet cables quick and easy.

Why Choose This Siemens RJ45 Plug?

• Fast Connection: Use the FastConnect system for tool-free installation.
• Works in Tough Places: Metal shell protects it in harsh industrial environments.
• Wide Temperature Range: Works from very cold -40°C to hot +85°C.
• Powers Devices: Supports PoE and PoE+ to deliver power over the cable.
• Universal Fit: Connects to standard 4-pair AWG22 Ethernet cables.

Full Product Specifications

• Brand & Model: Siemens 6GK1901-1BB10-2AA0
• Product Type: IE FC RJ45 Plug 180 (2x2)
• Data Speed: 10 Mbps and 100 Mbps for fast communication.
• Connections: 1 RJ45 port for your switch, 4 wires for the cable.
• Cable Direction: 180-degree side exit for neat cable routing.
• Durability: Can be connected and disconnected at least 10 times.
• Physical Size: 13.7 mm wide, 16 mm high, 55 mm deep.
• Weight: Very light at only 35 grams.
• Cable Size: Fits cables with a 6.5 mm outer diameter.
• Wire Gauge: Works with 0.33 mm² (AWG22) wires.
• Ingress Protection: IP20 rating for basic dust protection.
• Operating Humidity: Up to 95% (non-condensing).
• Certifications: Compliant with RoHS, UL, and cULus standards.
• Cable Category: Designed for Cat5e structured cabling.
• Environmental Data: Total carbon footprint of 0.277 kg CO2e.

What's in the Box & Shipping Info

• One Siemens IE FC RJ45 Plug (6GK1901-1BB10-2AA0).
• Secure packaging to prevent damage during transit.
• We ship worldwide using FedEx, UPS, or DHL.
• Orders are processed quickly for fast delivery.

Warranty & Support

• This product comes with a solid 12-month warranty.
• The warranty covers defects in materials and workmanship.
• Our support team is ready to help with any technical questions.

Frequently Asked Questions (FAQ)

• Do I need special tools to install this connector? No special tools are required. The FastConnect system lets you terminate the cable quickly without a crimping tool.
• Can I use this plug outside or in wet conditions? No, it has an IP20 rating. This means it is only for dry, indoor locations. Do not expose it to water or rain.
• What is the main advantage of the metal housing? The metal shell provides extra strength. It protects the connector from physical damage and electromagnetic interference in industrial panels.
• I need to power a sensor over Ethernet. Will this work? Yes. This plug supports both standard PoE (IEEE 802.3af) and PoE+ (IEEE 802.3at). It can deliver power to devices like IP cameras or sensors.
• How does this plug handle constant vibration on a machine? Its robust metal design and secure lock mechanism are made for such environments. It ensures the connection stays stable even with strong machine vibration.
