Bently Nevada 330192-00-10-15-00 Vibration Probe
Monitor your machinery with the Bently Nevada 330192-00-10-15-00 vibration probe. This 8mm ETR probe delivers reliable performance in tough conditions. The 330192-00-10-15-00 features armored construction for maximum durability and accuracy.
- Robust Design: Stainless steel body with armored cable protection
- Wide Temperature Range: Works from -52°C to +177°C
- Easy Installation: Standard 3/8-24 UNF thread
- Safety Certified: Approved for hazardous areas
Technical Specifications
Product Model: Bently Nevada 330192-00-10-15-00
Probe Type: 3300 XL 8mm ETR Vibration Sensor
Thread Size: 3/8-24 UNF
Case Length: 1.0 inch
Cable Length: 1.5 meters (4.9 feet)
DC Resistance: 7.73 ± 0.50 Ω
Tip Material: Polyphenylene Sulfide (PPS)
Case Material: AISI 303/304 Stainless Steel
Operating Temperature: -52°C to +177°C standard
Extended Temperature: Up to +218°C for probe tip
Humidity Rating: Less than 3% ASF change at 93% humidity
Pressure Seal: Viton O-ring
Maximum Thread Engagement: 0.563 inch
Hazardous Area Certification: Class I, Zone 0 & 2 approved
Weight: Approximately 0.2 kg
Cable Type: Armored coaxial
Warranty & Shipping
This product includes full 12-month warranty protection. We deliver worldwide through FedEx, UPS, and DHL services.
Frequently Asked Questions
What machinery is this probe designed for?
Perfect for turbines, compressors, pumps and other rotating equipment monitoring.
How do I choose the right cable length?
Select based on distance from machine to monitoring system, allowing some slack.
Can it handle high vibration environments?
Yes, the armored design withstands severe vibration and mechanical stress.
What maintenance does this probe require?
Regular calibration checks and visual inspection for cable damage are recommended.
Is special training needed for installation?
Basic mechanical skills are sufficient, but follow manufacturer gap setting procedures carefully.
