Bently Nevada 330192-00-10-20-00 Vibration Monitoring Probe
Ensure optimal machinery protection with the Bently Nevada 330192-00-10-20-00 vibration probe. This industrial-grade sensor delivers precise measurements for critical equipment. The 330192-00-10-20-00 offers extended reach with its 2-meter armored cable.
- Extended Cable Length: 2.0 meters for flexible installation
- Rugged Construction: Stainless steel body with armor protection
- Wide Temperature Operation: Performs from -52°C to +177°C
- Hazardous Area Ready: Certified for explosive environments
Technical Specifications
Product Model: Bently Nevada 330192-00-10-20-00
Probe Series: 3300 XL Vibration Monitoring System
Sensor Type: 8mm ETR Proximity Probe
Thread Specification: 3/8-24 UNF
Case Dimension: 1.0 inch length
Cable Length: 2.0 meters (6.6 feet)
Electrical Resistance: 7.88 ± 0.50 Ω
Tip Construction: Polyphenylene Sulfide (PPS)
Housing Material: AISI 303/304 Stainless Steel
Standard Temperature: -52°C to +177°C
High Temperature: Up to +218°C capability
Sealing System: Viton O-ring pressure seal
Thread Engagement: 0.563 inch maximum
Environmental Rating: IP67 equivalent
Humidity Performance: <3% ASF change at 93% RH
Safety Certifications: ATEX, IECEx compliant
Vibration Limit: 15g peak operating
Shock Resistance: 50g peak survival
Warranty & Shipping
This product is covered by a comprehensive 12-month warranty. We ship internationally using FedEx, UPS, and DHL for reliable delivery.
Frequently Asked Questions
What is the main advantage of the 2-meter cable?
It provides greater installation flexibility for hard-to-reach machinery locations.
How does this probe handle wet conditions?
The Viton O-ring seal and armored cable provide excellent moisture protection.
What tools are needed for installation?
Basic wrench for the 3/8-24 UNF thread and gap setting tools for calibration.
Can multiple probes be used on one machine?
Yes, typically X, Y and thrust position probes are installed for complete monitoring.
How often should calibration be performed?
Annual calibration is recommended for critical machinery protection systems.
