SICK DL100-22AA2112 Dx100 Time-of-Flight Sensor

• Long Range: Measures from 0.15 m up to 200 m on reflective tape.
• Fast & Precise: High 1 mm repeatability and fast 2 ms response.
• Versatile: PROFINET interface and two digital outputs for easy setup.
• Tough Design: IP65 metal housing for tough factory use.

Key Technical Data

Brand & Model: SICK DL100-22AA2112 (Dx100 Series)
Type: Time-of-Flight Laser Sensor
Measuring Range: 0.15 m to 200 m
Accuracy: ± 2.5 mm
Repeatability: 1 mm
Resolution: Adjustable (0.1 mm to 100 mm)
Response Time: 2 ms
Light Source: Visible Red Laser (Class 2)
Spot Size: 5 mm + (2 mm x distance in m)
Outputs: 2 x Digital (PNP/NPN), PROFINET
Input: 1 x Multifunctional (MF1)
Supply Voltage: 18-30 V DC
Current Draw: < 250 mA @ 24V
Housing Rating: IP65
Operating Temperature: –20°C to +55°C (up to +75°C with cooler)
Weight: ~800 g (sensor only)
Dimensions (WxHxD): 69.4 mm x 82.5 mm x 100.2 mm

Frequently Asked Questions (FAQ)

What is the farthest this sensor can measure? It can measure up to 200 meters when using special "diamond grade" reflective tape. For normal objects, the range is shorter. How fast can the DL100-22AA2112 take measurements? It is very fast. The measurement cycle time is 1 ms, and the response time is 2 ms. It can track objects moving up to 15 m/s. What kind of output signals does it have? It has two flexible digital outputs and a PROFINET interface. This allows it to send distance data or warning signals directly to your control system. Can it work in dusty or wet conditions? Yes. The sensor has an IP65 rating. This means it is protected against dust and water jets, making it good for most industrial areas. What happens if the sensor gets dirty? The sensor can send a service warning. This alert tells you if the lens is dirty, the temperature is too high, or if there is a problem with the measurement.
