Meggitt Vibro-Meter M10 Thread Proximity Sensor System

• M10 × 1 threaded body for easy installation
• 1-meter sensor cable with 1-meter protective hose
• 10-meter total system length for flexible routing
• IP68 rated for harsh industrial environments
• Complete 12-month product warranty included

Product Overview

This Meggitt Vibro-Meter proximity system features a convenient M10 threaded body. The proximity measuring system offers 10-meter total reach with integrated protective hose. Perfect for machinery vibration monitoring where threaded mounting is preferred. API 670 compliant for industrial applications.

Technical Specifications

Brand: Meggitt (Vibro-Meter)
Model: 111-412-000-013-A1-B1-E010-F1-G010-H10
Thread Size: M10 × 1
Sensor Cable: 1.0 meter ±100 mm
Protection Hose: 1.0 meter flexible
Total Length: 10 meters complete
Sensing Range: 2mm or 4mm options
Frequency: DC to 20 kHz (-3 dB)
Temperature: -40°C to +180°C
Coil Size: 8mm diameter
Weight: 0.22 kg

Mounting Features

Standard M10 × 1 threaded body
Easy screw-in installation
No additional mounting hardware needed
Quick installation and removal
Industry standard thread size

Cable Protection

1-meter flexible stainless steel hose
Mechanical damage protection
Abrasion resistant covering
Chemical resistant construction
IP68 waterproof rating

Performance Characteristics

Eddy-current non-contact principle
Temperature compensated design
5g vibration resistance
15g shock survival rating
Short-circuit protected output

System Integration

Requires IQS900 signal conditioner
VM600Mk2/VM600 compatible
VibroSmart® system ready
Self-locking connectors
70Ω coaxial cable system

Package Contents

1x M10 threaded proximity sensor
1m sensor cable with 1m protection hose
10m total system length
Installation instructions
12-month warranty coverage

Shipping Information

Fast delivery via FedEx, UPS, DHL
Worldwide express service
Secure protective packaging
Online tracking provided

Expert FAQ

What are the benefits of the M10 threaded design?
Quick installation without special brackets, secure mounting in high-vibration environments, and industry-standard compatibility.

How does the 10-meter total length affect installation flexibility?
Allows routing around obstacles and connection to remote monitoring equipment while maintaining signal integrity.

What types of machinery benefit most from threaded sensors?
Pumps, compressors, motors, and gearboxes where threaded mounting holes are standard in the industry.

Can the protective hose withstand oil and chemical exposure?
Yes, the stainless steel hose with FEP coating provides excellent resistance to oils, chemicals, and industrial fluids.

What is the recommended maintenance schedule?
Annual visual inspection and calibration check, though the system typically operates maintenance-free for extended periods.
