Meggitt Vibro-Meter Heavy-Duty Proximity Sensor with Full Protection

• Complete 9.5m system with flexible stainless steel hose
• FEP sheath for maximum chemical resistance
• IP68 rated for harsh industrial environments
• Ready for immediate installation and use
• Protected by 12-month quality warranty

Product Overview

This Meggitt Vibro-Meter proximity system comes with complete mechanical protection. The proximity measuring system includes a 9.3m flexible stainless steel hose with FEP sheath. Perfect for abrasive and chemical environments where cable protection is critical. Delivers reliable non-contact vibration measurement.

Technical Specifications

Brand: Meggitt (Vibro-Meter)
Model: 913-402-000-013/A1-E095-F2-G093
Cable Length: 9.5 meters total
Hose Length: 9.3 meters stainless steel
Protection: FEP chemical sheath
Sensing Range: 2mm or 4mm available
Frequency: DC to 20 kHz response
Temperature: -40°C to +180°C
Cable Type: 70Ω coaxial
Weight: 0.22 kg
Mounting: Two M4 screws

Protection Features

Flexible stainless steel hose cover
FEP chemical-resistant sheath
IP68 waterproof rating
Abrasion resistant construction
Crush and impact protection

Sensor Construction

AISI 316L stainless steel body
8mm diameter sensing coil
Torlon high-temperature tip
Epoxy encapsulated electronics
Self-locking quick connectors

Environmental Durability

Chemical resistant FEP coating
5g vibration immunity
15g shock resistance
Wide temperature operation
Humidity and moisture proof

Installation & Setup

Requires IQS900 conditioner
Two M4 mounting points
9.3m protected cable run
Hand-tighten connectors
VM600 compatible

Package Contents

1x Proximity sensor with protection
9.5m cable with 9.3m hose
Complete mounting hardware
Installation documentation
12-month warranty included

Shipping Services

Fast delivery via FedEx, UPS, DHL
Worldwide shipping available
Professional packaging
Online tracking provided

Expert FAQ

What environments require the FEP sheath protection?
Chemical plants, offshore platforms, and industrial settings with exposure to oils, solvents, and corrosive substances.

How does the stainless steel hose improve reliability?
It prevents cable damage from abrasion, crushing, and mechanical impact in high-traffic industrial areas.

Can the flexible hose be cut to custom lengths?
No, the system comes as a complete assembly to maintain integrity of the protective covering and certifications.

What maintenance is needed for long-term operation?
Regular visual inspection of the protective hose and periodic calibration checks ensure continued optimal performance.

How does temperature affect the FEP sheath performance?
The FEP material maintains flexibility and chemical resistance across the entire operating temperature range up to 200°C.
