Schneider Electric 140DIO33000 Intrinsically Safe Output Module
- Hazardous Area Certified
- Immediate Shipping Available
- Genuine Schneider Electric Product
- Expert Safety Application Support
Safe Operation in Hazardous Areas
The 140DIO33000 provides intrinsically safe outputs for explosive environments. This specialized module meets strict safety standards for zone 20, 21, and 22 applications.
Safety Features
ATEX certified - II1 G/D-EEx ia IIC rating
Open collector outputs - 24V DC operation
Current limited - 45mA maximum per point
Multiple protections - Internal fuses and voltage suppression
High isolation - 2500V DC protection
Technical Specifications
Brand: Schneider Electric
Model: 140DIO33000
Output Type: 8-Channel Open Collector
Output Voltage: 24V DC
Current per Point: 45mA maximum
Total Module Current: 360mA maximum
Response Time: 1ms switching
Leakage Current: 0.4mA per point off state
Power Dissipation: 5W maximum
Bus Current: 2.2A required
Isolation Rating: 2500V DC to bus
Safety Certification: ATEX, FM, GOST, SIRA
Weight: 0.45 kg (0.99 lb)
Application Information
Hazardous Zones: 20, 21, 22 compliant
Software Support: Unity Pro, Concept, ProWORX
Safety Standards: EN50014, EN50020, EN50039
Installation: Standard Quantum format
Package Includes
1 x 140DIO33000 Safety Module
Certification documentation
Ordering & Support
Fast delivery via FedEx, UPS, DHL
12-month performance warranty
Safety compliance guaranteed
Safety Questions
What makes this module intrinsically safe?
It limits electrical energy to prevent ignition in hazardous areas with flammable substances.
Where can I install this module?
It's certified for Zone 20, 21, and 22 areas with explosive dust or gas atmospheres.
What is the maximum current per output?
Each output can safely handle up to 45mA, with 360mA total for the entire module.
Can I replace this module while powered?
No, hot swapping is not permitted due to intrinsic safety requirements and standards.
What protection features are included?
It has internal fuses, transient voltage suppression, and 2500V isolation for safety.
