Schneider Electric 170INT11000 Interbus Communication Adapter
Connect your Momentum system to Interbus networks! The 170INT11000 adapter provides reliable communication:
- Designed for Modicon Momentum automation platforms.
- Uses Interbus SUPI II protocol at 500 kbit/s speed.
- Supports large networks: up to 254 devices per segment.
- Long cable runs: up to 1000 meters network distance.
- Ring topology for reliable data transmission.
Technical Specifications
Model: 170INT11000
Brand: Schneider Electric
Series: Modicon Momentum
Module Type: Interbus Communication Adapter
Protocol: Interbus Generation SUPI II
Data Rate: 500 kbit/s
Topology: Ring Network
Connectors: Two 9-pin D-Sub Interbus ports
Cable Type: Twisted pair
Devices per Segment: 0 to 254
Max Network Distance: 1000 meters
Max Module Distance: 400 meters between modules
Access Method: Master/Slave & Continuous Shift Register
Error Check: CRC-16 control parameter
Power Consumption: 200-400 mA at 5V DC
Power Dissipation: 0.8 Watt
Protection Rating: IP20
Operating Temp: 0°C to 60°C
Storage Temp: -40°C to 85°C
Weight: 0.07 kg (0.15 lb)
Installation & Setup
Install the 170INT11000 adapter on your Momentum I/O base. Connect Interbus devices using twisted pair cables in a ring topology. Use the two 9-pin D-Sub connectors for in and out connections. Configure as master or slave device. Ensure total network length does not exceed 1000 meters.
Compatibility
Made for Modicon Momentum systems. Connects Momentum platforms to Interbus SUPI II industrial networks.
Network Features
Supports large networks with up to 254 devices. Long-distance communication up to 1000 meters. Ring topology for data reliability. CRC-16 error checking for data accuracy. Fail-safe operation design.
Package & Warranty
Package Includes: One new 170INT11000 Interbus communication adapter.
Warranty: Full 12-month warranty against defects.
Frequently Asked Questions
Q: How many devices can I connect?
A: You can connect up to 254 devices on one Interbus segment.
Q: What cable should I use?
A: Use standard twisted pair cables for Interbus networks.
Q: How far can devices be apart?
A: Maximum 400 meters between two modules, 1000 meters total network length.
Q: What is ring topology?
A: Devices connect in a circle. Data travels around the ring for reliable communication.
Q: Is error checking included?
A: Yes, CRC-16 error checking ensures data transmission accuracy.
