Allen Bradley PowerFlex 753 Drive: 20F1AND186AN0NNNNN

Drive your critical processes with high-performance control. The Allen Bradley 20F1AND186AN0NNNNN is a powerful AC drive from the PowerFlex 753 series. Engineered for 480V systems, it delivers reliable operation for 150HP motors. Essential for heavy industrial applications.

• High Power Rating: 110 kW / 150 Horsepower output capability.
• Strong Current Output: Rated for 186 Amps continuous current.
• Integrated Connectivity: Features standard onboard I/O for direct control.
• Clean Operation: EMC filtered to minimize electrical noise.
• Robust Cooling: Air-cooled design ensures stable thermal performance.

Technical Specifications

Brand: Allen Bradley (Rockwell Automation)
Model: 20F1AND186AN0NNNNN
Series: PowerFlex 753 AC Drive
Type: General Motor Control AC Drive
Input Voltage: 480 V AC, 3-Phase
DC Bus Voltage: ~650 V DC
Output Current: 186 A
Rated Power: 110 kW / 150 HP
Protection Rating: IP20 / IP00 (Open Type)
Cooling Method: Air-cooled
Input Feature: AC with Pre-charge
Braking: None (Internal braking transistor not included)
Operator Interface: No Keypad / HIM Included
EMC Filtering: Filtered, Common Mode Jumper Removed
Built-in I/O: Standard Onboard Digital/Analog I/O
Weight: 36.32 kg (80.06 lbs)

Installation Guide

This open-type drive must be installed inside a protective electrical cabinet. Ensure sufficient space around the unit for adequate air cooling. Connect the three-phase 480V AC input power. Utilize the onboard I/O for control signals from push buttons, sensors, or a PLC. Professional installation following local codes is required.

Compatibility & Applications

Designed for controlling large three-phase AC motors in demanding environments. Ideal for applications such as large pumps, industrial fans, mixers, and main conveyor drives within manufacturing and processing plants.

Warranty & Shipping

This industrial drive is protected by a 12-month warranty. We arrange secure global shipping through reliable carriers: FedEx, UPS, and DHL.

Frequently Asked Questions

What size motor can this 186A drive control?
It is rated to control motors up to 150 HP (110 kW). Always verify your specific motor's full load ampere (FLA) rating matches the drive's 186A output.

How do I program the drive without a keypad?
Programming can be done using Allen Bradley's configuration software (like Connected Components Workbench) on a computer connected via a communication adapter, or by installing an optional Human Interface Module (HIM).

What does "EMC filtered, jumper removed" mean?
The drive has an internal Electromagnetic Compatibility filter. The common mode (CM) jumper is shipped in the "removed" position, which is a typical default for many installations to reduce ground loop currents. Install it per your site's electrical guidelines.

Is dynamic braking included?
No, this catalog number does not include an internal dynamic braking transistor. For applications requiring rapid deceleration or holding loads, an external braking resistor module is necessary.

Can this drive be used in a 400V system?
No. This model (20F1AND186AN0NNNNN) is specifically designed for a 480V AC, 3-phase input. For a 400V system, you need a different model from the PowerFlex 753 series.
