Bently Nevada 330191-00-08-05-00 Proximity Probe: Durable 8mm Vibration Sensor
The Bently Nevada 330191-00-08-05-00 is a premium 8mm proximity probe from the reliable 3300 XL series. This new sensor delivers exceptional durability and precise vibration monitoring for industrial equipment. It features a sturdy stainless steel construction and advanced connection technology. The probe guarantees accurate measurements in challenging operating conditions. We ship this genuine product worldwide via FedEx, UPS, and DHL carriers.
Key Features and Advantages
- The 3300 XL 8 mm probe design offers thicker coil encapsulation for enhanced physical protection
- Patented TipLoc molding creates a superior bond between probe tip and body for maximum reliability
- CableLoc technology ensures secure cable attachment with 330 N (75 lbf) pull strength rating
- Probe tip utilizes robust Polyphenylene sulfide (PPS) material for chemical and heat resistance
- Optional FluidLoc cable prevents oil and liquid migration through cable interior pathways
Complete Technical Specifications
- Brand: Bently Nevada
- Model: 330191-00-08-05-00 (3300 XL 8mm ETR Probe)
- Model Breakdown: 8mm probe without armor, minimal unthreaded length, 0.8" case, 0.5-meter cable
- Power Requirements: -17.5 Vdc to -26 Vdc operating range
- Output Resistance: 50 Ω standard impedance
- Probe Resistance: 7.45 ± 0.50 Ω for 0.5-meter version
- Case Material: AISI 303/304 stainless steel construction
- Cable Type: 75Ω triaxial with FEP insulation
- Temperature Range: -55°C to +232°C maximum operating span
Installation Guidelines
- Mount using standard 3/8-24 UNF threaded connection with proper engagement
- Maintain maximum thread engagement of 0.563 inches for secure fitting
- Connect only with genuine Bently Nevada extension cables and compatible systems
- Apply connector torque carefully without exceeding 0.565 N•m (5 in•lbf) limit
- Viton O-ring provides effective sealing between probe tip and case interior
Packaging Contents
- One genuine Bently Nevada 330191-00-08-05-00 proximity probe
- Original factory packaging ensuring product protection and authenticity
- Fast worldwide shipping available through FedEx, UPS, and DHL services
Frequently Asked Questions
- What does the 05 suffix indicate? It specifies the 0.5 meter total probe length configuration
- Is an extension cable necessary? Systems under one meter total length typically don't need extensions
- What temperature can it withstand? Operating range spans from -55°C to +232°C depending on classification
- Why select 8mm probe size? Larger diameter provides superior physical strength and damage resistance
- Are fluid-resistant options available? Yes, specify FluidLoc cable option for oil and liquid protection
