IC697PWR722 GE Fanuc 90W DC Power Supply Module | Series 90-70
Manufacturer:
GE
Product No.:
IC697PWR722
Condition:
In Stock
Product Type:
DC Power Supply Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Pouzdan globalni dobavljač delova za automatizaciju
Nudimo širok asortiman industrijskih rezervnih delova za automatizaciju koji su dostupni na lageru. Svi proizvodi dolaze sa 12-mesečnom garancijom i 30-dnevnim povraćajem novca zbog problema sa kvalitetom.
GE Fanuc IC697PWR722 90W DC Power Supply Module
The IC697PWR722 is a robust 90-watt DC power supply module from GE Fanuc's Series 90-70. This versatile unit supports dual rack operations for expanded industrial automation systems.
Technical Specifications
- Brand: GE Fanuc
- Series: Series 90-70
- Model: IC697PWR722
- Type: Power Supply Module
- Nominal Input Voltage: 24 VDC
- Input Voltage Range: 21-32 VDC
- Maximum Power: 156 Watts
- Output Power: 90 Watts maximum
- Inrush Energy: 22 J at 32 VDC
- Voltage Regulation: 5, 12, and -12 VDC
- Overvoltage Limit: 6 to 7 Volts
- Operating Temperature: 0-60°C
- Shock Resistance: 15 G for 11 milliseconds
Output Specifications
- +5 VDC Output: 16.5 Amps maximum current capacity
- +12 VDC Output: 1.5 Amps maximum current capacity
- -12 VDC Output: 1 Amp maximum current capacity
Dual Rack Operation
- This module can power two racks when specific conditions are met.
- The second rack must require only 5 volts of power for operation.
- Current drawn by the second rack cannot exceed 5.2 amps.
- Both racks must be positioned close to each other.
- The connecting cable between racks cannot exceed 3 feet in length.
Installation Options
- Mount with right side plate attached at the factory on a panel.
- Attach to the left side of the rack using additional hardware.
- The module installs on the left side of compatible system racks.
- It requires connection to a power supply adapter module like IC697PWR720.
- The adapter connects power outputs to the rack backplane.
Packaging & Shipping
- We ship all orders promptly using reliable carriers like FedEx, UPS, and DHL.
- Your package contains one IC697PWR722 power supply module.
Frequently Asked Questions (FAQ)
- What input voltage does it require? 21-32 VDC, nominal 24 VDC.
- Can it power two racks simultaneously? Yes, with specific current and distance limitations.
- What protection features does it offer? Circuit overcurrent protection for all inputs/outputs.
- What is the maximum output power? 90 watts total for all three outputs.
