SICK S30A-4011CA S3000 Advanced Safety Laser Scanner
Advanced protection for dynamic safety zones. The SICK S30A-4011CA from the S3000 Advanced series offers flexible area guarding. With 4 configurable field sets and a 4m protective range, it's ideal for applications requiring multiple safety layouts.
- Multi-Zone Flexibility: Store and switch between 4 different safety field sets.
- High Safety Standard: Certified to Type 3, SIL 2, PL d, Category 3 for reliable operation.
- Easy Connection: Integrated M12 system plug for quick and secure wiring.
- Robust Design: IP65 aluminum housing ensures durability in industrial environments.
Core Technical Specifications
Brand & Model: SICK S30A-4011CA (S3000 Advanced Series)
Protective Field Range: 4 m
Warning Field Range: Up to 49 m
Scanning Angle: 190°
Resolution: Configurable (30, 40, 50, 70, 150 mm)
Response Time: ≤ 60 ms
Safety Ratings: Type 3, SIL 2, PL d, Category 3
Field Set Capacity: 4 Sets (12 fields total)
Monitoring Cases: 4
Supply Voltage: 24 V DC (16.8 - 28.8 V DC)
Outputs: 2 OSSDs (500 mA), 3 Diagnostic Outputs
Connection: Male M12 5-pin System Plug
Enclosure Rating: IP65
Operating Temperature: –10 °C to +50 °C
Dimensions: 155 mm x 185 mm x 160 mm
Weight: 3.3 kg
Key Features & Functions
Dynamic Field Switching: Perfect for machines with different operating modes, allowing the safety zone to change as needed.
Simultaneous Monitoring: Can actively monitor up to 4 protective fields at once for complex layouts.
Integrated Safety Diagnostics: Features include multiple sampling, restart interlock, and external device monitoring (EDM).
Long-Term Reliability: Designed for a 20-year mission time with a very low probability of dangerous failure (PFHD 8.0x10⁻⁸).
Easy Configuration & Replacement: Field sets are stored in the system plug, enabling quick device swaps without reconfiguration.
Frequently Asked Questions (FAQ)
What is the main advantage of having 4 field sets?
It allows one scanner to protect a machine with multiple operating modes, each needing a different safety zone shape, without needing extra hardware.
Can I use this on an Automated Guided Vehicle (AGV)?
Yes. Its robust construction, 190° field of view, and multiple field sets make it an excellent choice for AGV front or side protection.
How do I switch between the different field sets?
Switching is typically done via external control signals connected to the scanner's inputs, allowing automatic changes based on the machine's state.
Is the M12 connection secure for mobile equipment?
Yes, the M12 connector is a standard industrial connection known for its vibration resistance and secure locking, ideal for mobile use.
What does the 49m warning field do?
It can detect objects or people at a far distance, allowing for a warning signal (like a light or buzzer) before they enter the closer 4m safety stop zone.
Package & Support
Package Includes: One SICK S30A-4011CA Safety Laser Scanner with M12 system plug.
Warranty: Backed by a 12-month warranty.
Shipping: Reliable global delivery via FedEx, UPS, and DHL.
