Bently Nevada 3300 XL 8mm Chemical-Resistant Proximity Probe

Introducing the 330103-00-07-10-12-00, a specialized vibration sensor for challenging environments. This model combines compact design with fluid resistance. The 330103-00-07-10-12-00 features FluidLoc cable technology. It protects against oils, chemicals, and moisture. Ideal for harsh industrial applications where reliability matters most.

Get complete technical details: Download Full Specifications

Technical Specifications

• Brand: Bently Nevada
• Product Series: 3300 XL Monitoring System
• Complete Model: 330103-00-07-10-12-00
• Sensor Type: 8mm Proximity Probe
• Thread Specification: M10 × 1.0 mm
• Unthreaded Section: 0mm (completely threaded)
• Case Dimensions: 70mm compact length
• Measurement Capability: 2.0mm (80 mils) range
• Optimal Sensing Distance: 1.27mm (50 mils)
• Voltage Output Range: -1 to -17 VDC
• Standard Output Level: -9 VDC for vibration
• Electrical Specification: 7.59 ± 0.50 Ω resistance
• Cable Technology: FluidLoc chemical-resistant
• Cable Length: 1.0 meter (3.3 feet)
• Connection System: ClickLoc secure connector
• Housing Material: 303/304 Stainless Steel
• Tip Material: PPS (Polyphenylene Sulfide)
• Sealing System: Viton O-ring protection
• Temperature Operating Range: -52°C to +177°C
• Unit Weight: 323 g/m (11.4 oz/ft)
• Maximum Cable Distance: 305 meters (1000 feet)
• Humidity Resistance: Less than 3% change at 93% RH

Model Number Breakdown

• 330103: 8mm probe with M10×1 thread configuration
• 00: Zero unthreaded length (fully threaded body)
• 07: 70mm total case length
• 10: 1.0 meter integrated cable
• 12: FluidLoc cable with ClickLoc connector
• 00: No agency approvals required

Warranty And Shipping

This product includes 12-month performance warranty. Worldwide shipping via FedEx, UPS, and DHL services. Expedited shipping options available for urgent requirements.

Expert Technical Questions

• What environments need FluidLoc cable?
  Areas with oil splash, chemical exposure, or high moisture levels.
• How does the 70mm length benefit installations?
  Provides compact sizing where space is limited but standard probes won't fit.
• Can this probe handle pressure washdowns?
  Yes, with proper connection protection and installation techniques.
• What maintenance does FluidLoc cable require?
  Regular inspection for damage and cleaning of connector areas.
• Is special training needed for installation?
  Standard mechanical installation skills are sufficient for proper mounting.
