AI-TEK 70085-1010-024: Ultra-Compact High-Temperature Speed Sensor

Product Highlights

• Extremely compact 1-inch length for space-constrained installations
• Exceptional high-temperature operation up to 232°C continuous
• Fine 1/4-40 thread for precision mounting applications
• Multiple cable length options from 8 inches to 60 inches
• Ultra-lightweight design at only 2 ounces maximum weight

Technical Specifications

• Physical Dimensions: 1.0-inch total length, 0.687-inch thread engagement
• Temperature Performance: -73°C to +232°C extreme range
• Voltage Output: 4.7V P-P standard, 0.4V P-P guaranteed minimum
• Electrical Characteristics: 125 ohms max resistance, 5-12 mH inductance
• Mounting Specification: 1/4-40 unified extra-fine thread
• Wire Options: 8-inch standard leads, 60-inch extended cable available
• Polarity Configuration: White wire indicates positive output
• Weight Specification: 2 ounces maximum total weight
• Frequency Response: 50kHz maximum for high-speed applications
• Supply Requirements: 3-18VDC recommended operating voltage

Environmental Durability

• Outstanding performance in extreme temperature environments
• Excellent thermal shock resistance for rapid temperature changes
• Vibration tolerance suitable for aerospace and precision machinery
• Stable signal output across the entire operational temperature range
• Reliable operation in chemically aggressive environments

Installation Instructions

• Mount using 1/4-40 fine thread with proper torque setting
• Connect white wire as positive output terminal
• Maintain precise air gap to target for optimal performance
• Select appropriate cable length for your application needs
• Use high-temperature compatible wiring for extended leads
• Verify signal quality after installation completion

Package Contents

• One AI-TEK 70085-1010-024 miniature speed sensor
• 8-inch high-temperature rated wire leads
• Comprehensive installation and technical guide
• All required components for immediate operation

Shipping Services

• Global delivery via FedEx express shipping
• UPS international delivery options available
• DHL worldwide courier service for urgent needs
• Complete tracking information provided

Warranty Coverage

• 12-month comprehensive product warranty
• Full protection against manufacturing defects
• Professional technical support included
• Prompt replacement service for valid claims

Technical Questions

• What applications need such a compact sensor design?
• The 70085-1010-024 fits tight spaces in aerospace and precision equipment
• How does the fine thread benefit precision applications?
• The 1/4-40 thread allows precise adjustment and secure mounting
• Can this sensor handle rapid temperature cycling?
• Yes, it withstands thermal shock from -73°C to 232°C repeatedly
• What is the advantage of the low inductance range?
• 5-12 mH inductance enables very high-frequency response capability
• Which industries typically use this sensor model?
• Aerospace, laboratory equipment, and high-precision manufacturing applications
