AI-TEK 70085-1010-037: Ultra-Miniature Speed Sensing Solution

Compact Design Advantages

• Extremely small 0.5-inch square profile for tight spaces
• Lightweight construction weighing only 1 ounce maximum
• 10-32 unified thread for precision mounting applications
• 18-inch wire leads for flexible connection options
• Broad temperature range from -55°C to 107°C operation

Detailed Technical Specifications

• Physical Dimensions: 0.5-inch cube design with 0.5-inch thread length
• Electrical Output: 13V P-P standard, 0.6V P-P guaranteed minimum
• Temperature Performance: -55°C to +107°C operational range
• Electrical Properties: 190 ohms max resistance, 10 mH inductance
• Mounting Specification: 10-32 unified fine thread standard
• Wire Configuration: 18-inch leads with white positive polarity
• Weight Specification: 1 ounce maximum total weight
• Frequency Response: 60kHz maximum for high-speed detection
• Supply Requirements: 5-20VDC recommended operating voltage
• Current Consumption: 8mA typical during normal operation

Environmental Capabilities

• Reliable performance across wide temperature variations
• Vibration resistance suitable for compact machinery applications
• EMI protection for electrically sensitive environments
• Moisture resistance for industrial operating conditions
• Long-term stability in continuous operation scenarios

Installation Guidelines

• Mount using 10-32 fine thread with precise torque control
• Connect white wire as positive output connection
• Maintain exact air gap specifications for optimal performance
• Route 18-inch wires with proper strain relief provisions
• Verify electrical polarity before system integration
• Test sensor output across expected speed ranges

Package Contents

• One AI-TEK 70085-1010-037 miniature sensor
• 18-inch wire leads with identified polarity
• Complete installation and technical documentation
• All necessary components for immediate operation

Shipping Services

• Worldwide delivery via FedEx express service
• UPS international shipping options available
• DHL global courier for time-sensitive requirements
• Complete tracking information provided

Warranty Terms

• 12-month comprehensive product warranty
• Full coverage for manufacturing defects
• Professional technical support included
• Prompt replacement service available

Expert Technical Questions

• What applications benefit from the ultra-compact design?
• The 70085-1010-037 serves robotics, medical devices, and small machinery
• How does the cube shape assist in installation?
• The square profile provides wrench flats for easy mounting in tight spaces
• What advantage does the 10-32 thread offer?
• This fine thread allows precise adjustment and secure mounting in thin materials
• Can this sensor handle high rotational speeds?
• Yes, its 60kHz response supports very high-speed rotation monitoring
• What industries typically use this miniature sensor?
• Laboratory equipment, precision instruments, and compact automation systems
