Flexem FC5-30MR-AC: Versatile AC Power PLC Controller
Meet the Flexem FC5-30MR-AC programmable controller. This robust unit delivers 30 I/O points with relay outputs for industrial control. Perfect for applications requiring AC power operation and reliable switching capability.
Key Benefits of FC5-30MR-AC
- AC Power Operation: Direct 220V AC connection
- Relay Output Flexibility: Controls AC/DC loads easily
- Multiple Communication: Ethernet and serial ports included
- Expandable System: Supports additional modules for growth
Complete Technical Specifications
- Product Model: Flexem FC5-30MR-AC
- Total I/O Points: 30 integrated channels
- Input Configuration: 18 digital input points
- Output Type: 12 relay contact outputs
- Relay Contact Rating: 2A @ 250V AC resistive
- Power Supply: 220V AC operation
- Voltage Range: 220V AC ±15% tolerance
- Frequency: 50/60 Hz compatible
- Communication Ports: Multiple interface options
- Ethernet Port: 10/100M self-adaptive
- Serial Port 1: RS232/RS485 configurable
- Serial Port 2: RS485 communication
- USB Interface: Type-C for programming
- Baud Rate Range: 4800 to 115200 bps
- Expansion Capability: 1 expansion board slot
- Max System Expansion: Up to 31 modules total
- Real-Time Clock: Built-in with battery
- Clock Accuracy: ±3 seconds per day
- Battery Life: 1 year backup power
- Modbus Channels: 2 independent ports
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -25°C to 70°C
- Humidity Range: 5% to 95% non-condensing
Expert Questions & Answers
What loads can the relay outputs control?
The relay outputs can switch both AC and DC loads up to 2A at 250V AC, making them versatile for various devices.
How does AC power benefit my application?
AC power allows direct connection to main power lines, eliminating the need for separate DC power supplies in many installations.
Can I connect to existing Modbus networks?
Yes, with two Modbus channels supporting both RS232 and RS485, it integrates easily into most industrial networks.
What expansion options are available?
You can add one expansion board directly and connect up to 31 I/O modules when used with compatible CPU units.
Is the real-time clock battery backed?
Yes, the built-in battery maintains clock operation for one year during power outages, ensuring accurate timekeeping.
