Flexem FC5-30MR-DC: Compact DC Power PLC with Relay Outputs

Discover the Flexem FC5-30MR-DC programmable controller. This efficient unit offers 30 I/O points with versatile relay outputs. Perfect for DC power systems requiring reliable switching and multiple communication options.

Why Choose This PLC?

• DC Power Operation: 24V DC for industrial safety
• Universal Relay Outputs: Controls both AC and DC loads
• Multiple Connectivity: Ethernet, serial ports, and USB-C
• Easy Expansion: Room for additional I/O modules

Technical Specifications

• Product Model: Flexem FC5-30MR-DC
• Total I/O Points: 30 integrated channels
• Input Points: 18 digital inputs
• Output Type: 12 relay outputs
• Relay Rating: 2A @ 30V DC / 250V AC
• Contact Life: 100,000 operations minimum
• Power Supply: 24V DC operation
• Voltage Range: 20.4V to 28.8V DC
• Power Consumption: 15W maximum
• Ethernet Port: 10/100M self-adaptive
• Serial Port 1: RS232/RS485 selectable
• Serial Port 2: RS485 communication
• USB Interface: Type-C for programming
• Baud Rates: 4800 to 115200 bps
• Expansion Slot: 1 expansion board supported
• Max System Size: Up to 31 modules total
• Real-Time Clock: Built-in with backup
• Clock Accuracy: ±3 seconds daily
• Backup Duration: 1 year data retention
• Operating Temp: 0°C to 55°C
• Storage Temp: -25°C to 70°C
• Product Weight: 450 grams
• Dimensions: 90mm × 100mm × 75mm

Frequently Asked Questions

What are the advantages of relay outputs?

Relay outputs can switch both AC and DC loads, providing flexibility for controlling different types of devices and voltages.

How many devices can I connect to the communication ports?

With Ethernet, two serial ports, and USB, you can connect multiple devices including computers, HMIs, and other PLCs simultaneously.

What is the relay contact life expectancy?

The relays are rated for at least 100,000 operations, ensuring long service life for typical industrial applications.

Can I use this in safety-critical applications?

While reliable for industrial use, always implement proper safety circuits and redundancies for critical safety functions.

How do I program this controller?

Use the USB Type-C port with Flexem programming software for easy setup, monitoring, and firmware updates.

Warranty & Support

Complete 12-month protection plan included with professional technical support available.
