E82ZAFCC201 Lenze Function Module | 8200 Series I/O

En existencia
Manufacturer:
Lenze
Product No.:
E82ZAFCC201
Condition:
In Stock
Product Type:
Function Modules
Product Origin:
DE
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Proveedor Global de Piezas de Automatización Confiable

Ofrecemos una amplia gama de piezas de repuesto para automatización industrial en stock. Todos los productos cuentan con una garantía de 12 meses y un reembolso de 30 días por problemas de calidad.

Sobre Nosotros | Contacto

E82ZAFCC201 Function Module: Reliable I/O for Lenze 8200-Series Drives

Key Technical Specifications

  • Brand & Model: Lenze E82ZAFCC201 function module for 8200-series drives.
  • Cable Type: Requires shielded pair cable with 120Ω impedance (95 to 140Ω range).
  • Signal Delay: 5 ns/m typical propagation time.
  • Input Resistance (X3.2/E1): 3.3 kΩ. LOW = 0-3V (HTL), HIGH = 12-30V (HTL).
  • Frequency Input (E1): Configurable via C0425 – 0-10 kHz (single channel) or 0-1 kHz (dual channel).
  • Drive Inhibit (CINH) on X3.3/28: Input resistance 3.3 kΩ. RUN = HIGH (12-30V), STOP = LOW (0-3V).
  • Reference Voltage (X3.3/20): U = 20V. Max load 0.6W.

Cable Length & Wire Size Guidelines

  • Cable length ≤ 300 m: Use 0.25 - 0.34 mm² (AWG22) with resistance ≤ 70Ω/km.
  • Cable length 301 - 1000 m: Use 0.5 mm² (AWG20) with resistance ≤ 40Ω/km.
  • Always use shielded twisted pair cable for reliable signal transmission.

Terminal Connection Specifications (X3.2 / X3.3)

  • X3.2 / E1* (Frequency Input): Reference = GND2. HTL level (0-3V LOW, 12-30V HIGH).
  • X3.3 / 7 (Reference Potential 1): Common ground reference for inputs.
  • X3.3 / 39 (Reference Potential 2): Dedicated reference for drive inhibit (CINH).
  • X3.3 / 28 (Drive Inhibit Input): Enables or disables the drive. HIGH = run, LOW = stop.
  • X3.3 / 20 (Auxiliary Voltage Output): Supplies 20V DC at max 0.6W for external sensors.

Frequently Asked Questions (FAQ)

  • Q: Which drives work with the E82ZAFCC201 module?
    A: This module fits Lenze 8200-series drives. Check your drive model for compatibility.
  • Q: What cable type does the E82ZAFCC201 require?
    A: You need a shielded twisted pair cable with 120Ω characteristic impedance.
  • Q: Can I use this module for high-speed counting?
    A: Yes. The frequency input supports 0-10 kHz single channel or 0-1 kHz dual channel via C0425.
  • Q: What voltage levels does the drive inhibit input accept?
    A: HIGH (12-30V) = drive runs. LOW (0-3V) = drive stops. Input resistance is 3.3 kΩ.
  • Q: Is the E82ZAFCC201 still in production?
    A: No. Lenze marks this product as Phase-Out. We offer remaining stock while available.
  • Q: What is the maximum cable length for reliable operation?
    A: Up to 1000 meters using 0.5 mm² (AWG20) shielded cable. Keep total resistance within limits.
