GE Fanuc IC697ALG441 - High-Density Voltage Expander Module

The IC697ALG441 from GE Fanuc provides 16-channel analog input expansion for Series 90-70 PLC systems. This voltage expander module offers precise signal acquisition with excellent noise rejection capabilities.

Technical Specifications

• Brand: GE Fanuc
• Model: IC697ALG441 (Full Suffix: IC697ALG441)
• Series: Series 90-70 PLC
• Type: Voltage Expander Module
• Input Channels: 16 differential inputs
• Voltage Range: -10V to +10V
• Input Impedance: >10 megohms
• Conversion Rate: 2ms
• Calibration: Factory set at 10V ±2mV
• Accuracy: ±0.03% of full value, ±0.02% of reading
• Power Requirement: 0.4A @ +5V (2 watts)
• Isolation: Field inputs isolated from backplane
• Weight: 4 pounds (1.81 kg)
• Operating Temp: 0°C to 60°C (32°F to 140°F)
• Warranty: 12 months

Electrical Characteristics

• Maximum Error: ±0.03% full scale, ±0.02% reading
• Common Mode Rejection: >120dB @ 60Hz
• Noise Rejection: Excellent differential noise immunity
• Signal Type: Differential voltage inputs
• Sampling Rate: 500 samples/second (total)

Configuration & Installation

• Configuration: Windows/MS-DOS configuration software
• DIP Switches: Not required - software configurable
• Expansion: Daisy-chain up to 7 modules (120 inputs)
• Wiring: AWG 22-14 wire size compatibility
• Installation: Power-off installation for terminal boards

Compatibility

• IC697ALG base converter modules
• Series 90-70 expansion modules
• MS-DOS and Windows configuration software
• Standard industrial terminal blocks

Performance Advantages

• Minimizes initial material and inventory costs
• Maximizes input utilization and system efficiency
• Easy to configure and integrate
• Reliable factory calibration
• Excellent long-term stability

Physical Specifications

• Dimensions: Standard Series 90-70 module size
• Mounting: DIN rail or panel mount
• Connectors: Removable terminal blocks
• Indicators: Status LEDs for channel activity
• Enclosure: Industrial-grade metal housing

Shipping & Delivery

• Shipping Methods: FedEx, UPS, DHL Express
• Packaging: Anti-static protective packaging
• Weight: 4 lbs (1.81 kg) including packaging
• Lead Time: 3-7 business days
• Return Policy: 30-day satisfaction guarantee

Application Notes

• Industrial process control systems
• Test and measurement applications
• Data acquisition systems
• Quality control monitoring
• Research and development setups
